Description
The Voltage Protection Relay protects the system against voltage line problems. Undervoltage, overvoltage, phase unbalance, phase failure, wrong phase sequence, and neutral disconnection faults are all protected by the relay. For convenient selection of nominal voltage, system type, trip delay, and fault trip point, front adjustment knobs are provided. The consumer has the option of selecting 3P3W or 3P4W on-site. Undervoltage and overvoltage faults can be disabled, but other problems cannot. Under-voltage relays safeguard loads from voltage decreases that might cause brownouts and power shortages. When the voltage drops below a specified threshold, the relay contacts trip the circuit breaker.
Key Features:
- All flaws are self-correcting.
- Multiple LEDs indicate the sort of defect, that aids in diagnosis.
- Potentially free relay contacts connect or disconnect loads or trigger an alarm for notification.
- The relay operates in a fail-safe mode.
- Motor protection, conveyor systems, and process industries, among other things.
Specifications:
- SKU: 3854138
- Weight: 0.11 LBS
- Diagram Reference Number: 5
- Alternate Products SKU: "REC3854138", "3854138"
- Manufacturer Part Number (MPN): 3854138
Volvo Penta Exploded view / schematic Engine Harness Bracket
