Description
80W Briefcase Solar Panel | Boat Supply Store
Maintain essential battery charge on extended voyages with this 80W briefcase solar panel. Its high-efficiency monocrystalline silicon cells deliver a maximum power output of 80 watts, ideal for replenishing 12V battery banks on smaller cruising sailboats or remote research vessels operating in the Gulf of Mexico. The integrated kickstand allows for optimal sun angle alignment, maximizing energy capture in diverse marine environments.
Key Features
- Maximize solar harvesting with high-efficiency monocrystalline cells.
- Power essential electronics with a robust 80W output.
- Deploy rapidly with the integrated briefcase design.
- Ensure optimal sun exposure via the adjustable kickstand.
- Protect against the elements with durable construction.
- Charge 12V battery systems efficiently.
- Ideal for sailboats and smaller cruising vessels.
- Lightweight and portable for flexible placement.
Specifications
| Product Specifications | |
|---|---|
| Power Output | 80W |
| Cell Type | Monocrystalline Silicon |
| Voltage | 12V (nominal) |
| Open Circuit Voltage (Voc) | 21.6V |
| Short Circuit Current (Isc) | 4.78A |
| Maximum Power Current (Imp) | 4.44A |
| Dimensions (Folded) | 370mm x 530mm x 40mm |
| Dimensions (Unfolded) | 740mm x 530mm x 20mm |
| Weight | 5.7 kg |
Who This Is For
This solar panel is engineered for boaters requiring reliable, portable power to maintain battery charge during extended offshore excursions. It is particularly suited for owners of smaller cruising sailboats and auxiliary vessels needing supplemental energy without a permanent installation.
How It Compares
| Feature | 80W Briefcase Solar Panel | Renogy |
|---|---|---|
| Max Power Output | 80W | 100W |
| Cell Type | Monocrystalline | Monocrystalline |
| Integrated Kickstand | Yes | Yes |
| Portability | Briefcase Design | Foldable Panel |
Common Concerns Answered
Will this panel reliably charge my batteries in overcast conditions?
While direct sunlight yields optimal performance, monocrystalline cells maintain a higher efficiency in lower light conditions compared to other types, providing a trickle charge to keep your 12V batteries topped off.
Is this panel durable enough for the marine environment?
Constructed with robust materials and designed for outdoor deployment, this panel is built to withstand typical marine conditions, though direct saltwater immersion should be avoided.
How difficult is it to set up and use this solar panel?
The briefcase design with an integrated kickstand allows for immediate deployment and optimal angle adjustment, requiring minimal setup time for basic operation.
Frequently Asked Questions
What is the maximum power delivery of this 80W panel?
The maximum power output is rated at 80 watts under standard test conditions.
What type of battery system is this panel compatible with?
This panel is designed for nominal 12V battery systems, suitable for common marine battery banks.
What are the physical dimensions when the panel is folded?
When folded into its briefcase form, the dimensions are 370mm x 530mm x 40mm.
Can I connect multiple of these panels together?
While this unit is self-contained, advanced users can explore series or parallel connections with appropriate charge controllers and wiring, though this is not a standard feature of the product.
What is the voltage and current output under load?
Under maximum power, the panel delivers approximately 18V at 4.44A.
