Actisense PRO NMEA 0183 Multiplexer | Boat Supply Store
For complex NMEA 0183 networks requiring robust data integration and isolation, this multiplexer efficiently consolidates signals. It features 5 OPTO-Isolated NMEA 0183 inputs and 2 ISO-Drive NMEA 0183 outputs, supporting configurable baud rates from 4800 to 38400 bps. Designed for professional installations on commercial vessels or advanced recreational craft, it ensures reliable data flow through its RINA type-approved 316 Stainless Steel housing.
Key Features
- Consolidate Signals with 5 OPTO-Isolated NMEA 0183 Inputs
- Protect Your Network with 2 ISO-Drive NMEA 0183 Outputs
- Seamless Integration via Ethernet & Serial Connections
- Intelligent Data Management with Auto-switching Between Inputs
- Optimized Performance via Configurable Baud Rates (4800-38400 bps)
- Precise Data Control with Sentence-Level Filtering
- Simplified Operation via Web-based UI for Easy Configuration
- Assured Compliance with RINA Type-Approved Certification
Specifications
| Product Specifications | |
|---|---|
| Number of NMEA 0183 Inputs | 5 isolated |
| Number of NMEA 0183 Outputs | 2 isolated with ISO-Drive |
| Serial Port | 1 bi-directional isolated serial port |
| Ethernet | 10/100BaseT for configuration and NMEA 0183 streaming |
| NMEA 0183 Baud Rate Support | 4800-38400 bps |
| Serial Port Baud Rate Support | Up to 115200 bps |
| Type Approval | RINA |
| Ingress Protection Rating | IP40 |
| Housing Material | 316 Stainless Steel |
| Power Input | 9-35V DC |
| Configuration Method | Web-based UI |
| Additional Features | Auto-switching, Sentence filtering, Multiple diagnostic LEDs, NMEA 0183 data streaming over Ethernet |
Who This Is For
Marine electronics installers and boat owners requiring advanced integration of multiple NMEA 0183 devices will find this multiplexer indispensable for its routing and isolation capabilities. Commercial vessel operators can rely on its type-approved status and robust build for demanding operational environments.
How It Compares
| Feature | Actisense PRO NMEA 0183 Multiplexer | Outputs |
|---|---|---|
| Number of NMEA 0183 Inputs | 5 | 4 |
| Number of NMEA 0183 Outputs | 2 | 4 |
| Ethernet Connectivity | Yes | No |
| Dedicated Serial Port | Yes (Bi-directional, Isolated) | No |
| Auto-switching | Yes | No |
| Sentence Filtering | Yes | No |
| ISO-Drive Isolation | Yes (Outputs) | Yes |
| Type Approval | RINA | No |
Common Concerns Answered
Is the advanced configuration difficult for beginners?
While the physical installation is straightforward, configuring advanced features like baud rates and sentence filtering requires familiarity with NMEA 0183 protocols. For complex setups, consulting the detailed manual or seeking installer assistance is recommended.
Are two outputs sufficient for a large network?
The PRO-NDC-1E provides two primary NMEA 0183 outputs, which may be a limitation for exceptionally large networks. However, its Ethernet NMEA 0183 streaming capability significantly expands data distribution possibilities.
Is this multiplexer overkill for a simple NMEA 0183 setup?
This unit offers advanced features and robust isolation that might exceed the requirements of basic installations. However, for users prioritizing future expandability, superior data integrity, and type-approved reliability, the investment is justified.
Frequently Asked Questions
What is the primary function of the Actisense PRO NMEA 0183 Multiplexer?
The primary function is to reliably combine data from multiple NMEA 0183 sources and route it to various displays or other devices, while also allowing for advanced filtering and streaming over Ethernet.
How many NMEA 0183 inputs and outputs does the PRO-NDC-1E have?
The PRO-NDC-1E features 5 isolated NMEA 0183 inputs and 2 isolated NMEA 0183 outputs equipped with ISO-Drive technology.
Can the PRO-NDC-1E handle different baud rates for NMEA 0183 devices?
Yes, the PRO-NDC-1E supports configurable baud rates from 4800 bps up to 38400 bps for its NMEA 0183 inputs and outputs, accommodating a wide range of marine electronics.
Does the PRO-NDC-1E offer isolation for connected devices?
Yes, all 5 NMEA 0183 inputs are OPTO-Isolated, and the 2 NMEA 0183 outputs utilize Actisense's proprietary ISO-Drive technology for enhanced protection against electrical issues.
How is the PRO-NDC-1E configured?
Configuration is performed through an intuitive web-based user interface accessed via the device's Ethernet connection, allowing for easy management of input routing, baud rates, and filtering rules.
