BEP 100A Marine Solenoid for Engine Starting | Boat Supply Store
This BEP 100A solenoid is engineered to reliably manage high-amperage engine starting loads via a low-amperage control switch, preventing overload on sensitive dash switches. It features a robust 750A make and 100A break current rating, ideal for the demands of cranking a marine engine. The intermittent duty cycle, rated for 10 seconds ON followed by 20 minutes OFF, is precisely suited for ignition sequences, ensuring longevity and preventing thermal damage during operation. This component is a direct electrical and physical equivalent to the Cole Hersee M-200, simplifying retrofits for Gulf Coast fishing vessels and offshore cruisers alike.
Key Features
- Reliable intermittent switching of high amperage engine starting loads
- Robust 750A make and 100A break current ratings
- Optimized for intermittent use: 10 seconds ON, 20 minutes OFF
- Efficient control with low amperage on-off switches
- Universal 12V DC signal voltage
- Versatile 6-12V DC contact voltage compatibility
- Convenient #10/32 thread signal terminals
- Durable copper 5/16"-24 thread contact terminals
Specifications
| Product Specifications | |
|---|---|
| Brand | BEP Marine |
| Model | 100A Engine Starting Intermittent Duty Solenoid |
| SKU | CWR67470 |
| MPN | 1002206 |
| Voltage | 12V DC signal, 6-12V DC contact |
| Current Rating | 750A make / 100A break |
| Duty Cycle | Intermittent duty cycle (10s ON/20min OFF) |
| Signal Terminals | #10/32 thread |
| Contact Terminals | 5/16"-24 thread copper |
| Mounting Holes | 5/16" x 19/32" on 2-13/64" centers |
| Equivalent To | Cole Hersee M-200 |
Who This Is For
Marine enthusiasts and boat owners requiring a dependable solenoid for engine cranking applications that necessitate intermittent high amperage switching. Marine mechanics will also find this a crucial component for reliable system repairs and upgrades.
How It Compares
| Feature | BEP 100A Marine Solenoid for Engine Starting | Cole Hersee |
|---|---|---|
| Model Number | 1002206 | M-200 |
| Signal Voltage | 12V DC | 12V DC |
| Contact Voltage | 6-12V DC | 6-12V DC |
| Make Amperage Rating | 750A | 750A |
| Break Amperage Rating | 100A | 100A |
| Duty Cycle | Intermittent (10s ON, 20min OFF) | Intermittent |
| Signal Terminal Type | #10/32 thread | #10/32 thread |
| Contact Terminal Type | Copper 5/16"-24 thread | Copper 5/16"-24 thread |
| Mounting Hole Dimensions | 5/16" x 19/32", 2-13/64" on center | 5/16" x 19/32", 2-13/64" on center |
Common Concerns Answered
Is this solenoid suitable for continuous duty applications?
No, this BEP 100A solenoid is specifically designed for intermittent duty cycles, rated for 10 seconds of operation followed by a 20-minute rest period. Continuous operation will lead to overheating and premature failure.
Can I use a low-amperage switch to control this solenoid?
Yes, the primary function of this solenoid is to allow a low-amperage switch to safely control the high-amperage circuit required for engine starting. The #10/32 signal terminals are designed for this purpose.
What is the difference between the make and break current ratings?
The 750A make rating indicates the maximum surge current the solenoid can safely handle when initially closing the circuit for engine cranking. The 100A break rating refers to the continuous current it can safely interrupt. This distinction is critical for engine starting applications.
Frequently Asked Questions
What is the intermittent duty cycle for the BEP 100A Engine Starting Solenoid?
The intermittent duty cycle for this solenoid is rated for 10 seconds of operation (ON) followed by 20 minutes of rest (OFF).
What is the signal voltage and contact voltage for this solenoid?
The signal voltage is 12V DC, and the contact voltage is compatible with 6-12V DC systems.
What type of terminals does this solenoid use?
It features #10/32 thread signal terminals for control and 5/16"-24 thread copper terminals for the main high-amperage battery connections.
What are the dimensions of the mounting bracket holes?
The mounting bracket holes are 5/16" wide by 19/32" long, spaced 2-13/64" on center.
What is the make and break current rating of this solenoid?
This solenoid has a make current rating of 750A and a break current rating of 100A.
