Blue Sea 1210 120V AC 4-Position Rotary Switch | Boat Supply Store
This 4-position 120V AC rotary switch by Blue Sea Systems provides robust control for multiple onboard electrical circuits, ideal for managing shore power and onboard generator inputs. It features a maximum continuous rating of 30A at 120V AC, ensuring dependable operation for essential systems. This unit is crucial for vessels operating in the Gulf Coast, managing the switch between shore power sources and auxiliary generators.
Key Features
- Consolidate multiple AC circuits onto a single control point.
- Isolate circuits effectively for maintenance or troubleshooting.
- Select between four distinct AC power sources.
- Maintain 30A continuous current capacity at 120V AC.
- Durable construction for marine environments.
- Simple rotary operation for intuitive control.
- Designed for panel mounting in electrical systems.
- Reliable switching for critical onboard power.
Specifications
| Product Specifications | |
|---|---|
| Voltage Rating | 120V AC |
| Amperage Rating (Continuous) | 30A |
| Number of Positions | 4 |
| Terminal Type | Screw |
Who This Is For
Marine electricians and boat owners requiring precise control over multiple 120V AC power sources. Essential for managing shore power, generator inputs, and inverter circuits on vessels with complex electrical configurations.
How It Compares
| Feature | Blue Sea 1210 120V AC 4-Position Rotary Switch | Guest |
|---|---|---|
| Voltage Rating | 120V AC | 120V AC |
| Amperage Rating (Continuous) | 30A | 30A |
| Number of Positions | 4 | 4 |
Common Concerns Answered
Will this switch handle my boat's inverter output?
The Blue Sea 1210 is rated for 30A continuous at 120V AC, which is suitable for many standard marine inverter systems. Always verify your inverter's output amperage to ensure compatibility.
Is this switch suitable for DC applications?
No, the Blue Sea 1210 is specifically designed and rated for 120V AC applications only. Using it for DC circuits will result in improper function and potential failure.
How do I mount this switch in my panel?
This rotary switch is designed for panel mounting. It typically requires a cutout of a specific diameter, and mounting hardware is usually included or easily sourced to secure it firmly in place.
Frequently Asked Questions
What is the maximum continuous current this switch can handle?
The Blue Sea 1210 is rated for a maximum continuous current of 30 Amperes at 120 Volts AC.
How many different power sources can this switch manage?
This is a 4-position rotary switch, allowing you to select and manage up to four different AC power sources or circuit configurations.
What type of terminals does the Blue Sea 1210 use?
The Blue Sea 1210 utilizes screw terminals for secure electrical connections.
Can this switch be used for shore power and generator selection?
Yes, this switch is ideal for selecting between shore power inputs and onboard generator outputs on a 120V AC system.
What is the primary function of a 4-position AC rotary switch on a boat?
Its primary function is to provide a single point of control for selecting and switching between multiple 120V AC circuits or power sources, such as shore power, generator, or inverter.
