Blue Sea 1223 12V DC 12 Position Panel | Boat Supply Store
This panel is engineered for efficient 12V DC power distribution and protection on recreational vessels. It offers twelve pre-wired positions, each protected by a 15A A-Series circuit breaker, capable of handling up to 100A per bus. With compact dimensions of 10.75" H x 4.88" W x 3.00" D, it facilitates organized management of critical electronics for offshore fishing platforms or coastal cruising yachts.
Key Features
- Organize 12 distinct 12V DC circuits with a single, consolidated panel.
- Protect sensitive onboard electronics with twelve included 15 Ampere A-Series Flat Rocker Circuit Breakers.
- Expand capacity for up to 32 branch circuits with installed breakers.
- Manage significant power loads with a maximum amperage of 100A per bus.
- Identify circuits easily with the included 4205 Basic DC Label Kit.
- Ensure reliable operation with Blue Sea Systems' robust marine-grade construction.
- Optimize space with compact dimensions: 10.75" H x 4.88" W x 3.00" D.
- Achieve professional installation with UL Listed safety certification.
Specifications
| Product Specifications | |
|---|---|
| 12-position | 12-position |
| voltage | 12V DC |
| maximum amperage per bus | 100A |
| circuit breakers included | Twelve 15A Single Pole A-Series Flat Rocker Circuit Breakers |
| label kit included | 4205 Basic DC Label Kit (30 black square labels) |
| dimensions | 10.75" H x 4.88" W x 3.00" D |
| weight | 4.85lb |
Who This Is For
This panel is designed for boat owners and marine technicians who require a pre-configured and reliable solution for managing multiple 12V DC circuits. It is ideal for vessels needing up to twelve protected branch circuits, offering a streamlined approach to electrical system organization.
How It Compares
| Feature | Blue Sea 1223 12V DC 12 Position Panel | Competitor |
|---|---|---|
| Number of Positions | 12 | 12 |
| Circuit Protection Type | Thermal Circuit Breaker (A-Series) | Blade Fuse |
| Included Breakers/Fuses | 12 x 15A Single Pole A-Series | Typically less capable |
| Max Amperage per Bus | 100A | 100A |
| Dimensions (H x W x D) | 10.75" x 4.88" x 3.00" | 7.25" x 5.38" x 3.00" |
| Labeling Kit Included | Yes (4205 Basic DC Label Kit) | No |
Common Concerns Answered
Is the initial cost of the Blue Sea 1223 higher than simpler fuse blocks?
Yes, the Blue Sea 1223 offers a significant advantage with integrated circuit breakers, providing superior protection and organization over basic fuse blocks, which can justify the initial investment for critical systems.
What if the included 15A breakers are not suitable for my specific circuits?
The Blue Sea 1223 is designed to accommodate various circuit loads; if 15A breakers are not optimal for certain applications, you can easily purchase and install alternative amperage A-Series breakers from Blue Sea Systems.
How does the Blue Sea 1223 panel compare in terms of build quality and reliability?
Blue Sea Systems is a highly respected brand in the marine industry, known for its robust build quality and unwavering reliability, ensuring the longevity and performance of your vessel's electrical systems in harsh marine environments.
Frequently Asked Questions
What is the maximum amperage rating for the Blue Sea 1223 12V DC 12 Position panel?
The Blue Sea 1223 panel has a maximum amperage rating of 100A per bus.
What type of circuit breakers are included with the Blue Sea 1223 panel?
The panel includes twelve 15 Ampere A-Series Flat Rocker Circuit Breakers, which are single-pole thermal breakers.
Can I add more branch circuits to the Blue Sea 1223 panel beyond the 12 positions?
The panel itself has 12 breaker positions. However, it is designed to accommodate up to 32 branch circuits when breakers are installed, allowing for complex system configurations.
What are the dimensions of the Blue Sea 1223 panel?
The dimensions of the Blue Sea 1223 panel are 10.75 inches in height, 4.88 inches in width, and 3.00 inches in depth.
Does the Blue Sea 1223 panel come with labeling options?
Yes, the Blue Sea 1223 panel includes the 4205 Basic DC Label Kit, which provides 30 black square labels for clear circuit identification.
