Description
Blue Sea 1450 DC 8-Position Panel | Boat Supply Store
For efficient and organized DC electrical management in compact marine environments, this 8-position panel consolidates circuit protection for vessels up to 24V. It features a robust 90A maximum system amperage and a space-saving 4.75" H x 4.88" W footprint, ideal for managing auxiliary electronics on offshore fishing boats. Each of the eight positions comes pre-equipped with 15A push-button reset circuit breakers, ensuring immediate system recovery after an overload.
Key Features
- High-density circuit protection for space efficiency
- 8 positions for comprehensive circuit management
- Includes resettable push-button circuit breakers
- Integrated labeling kit for clear circuit identification
- Suitable for 12V and 24V DC nominal voltage systems
- UL Listed for verified safety compliance
- Compact square format for easy panel integration
- Blue Sea Systems quality for marine-grade reliability
Specifications
| Product Specifications | |
|---|---|
| Number of Positions | 8 |
| Maximum System Amperage | 90A |
| Nominal Voltage | 12V DC / 24V DC |
| Dimensions (H x W x D) | 4.75" x 4.88" x 3.50" |
| Weight | 1.25lb |
| Included Circuit Breakers | (8) - 7056 - Push Button Reset Only Quick Connect Circuit Breaker - 15 Amps |
| Included Label Kit | 4205-Square Format Label Set |
| Safety Certification | UL Listed |
Who This Is For
Marine enthusiasts and boat owners requiring a robust, integrated solution for DC electrical distribution and protection on vessels up to 24V. It is also an effective choice for marine electricians seeking a reliable and compact panel for custom installations.
How It Compares
| Feature | Blue Sea 1450 DC 8-Position Panel | Competitor |
|---|---|---|
| Number of Positions | 8 | 6 |
| Number of Positions | 8 | 12 |
| Circuit Protection Type | Push Button Reset Circuit Breaker | Blade Fuse |
| Circuit Protection Type | Push Button Reset Circuit Breaker | Blade Fuse |
| Maximum Amperage (System) | 90A | 30A per block |
| Maximum Amperage (System) | 90A | 30A per block |
| Included Breakers/Fuses | (8) - 15A Push Button Reset Circuit Breakers | Typically less capable |
| Included Breakers/Fuses | (8) - 15A Push Button Reset Circuit Breakers | Typically less capable |
| Labeling Kit Included | Yes (4205 Basic DC Label Kit) | No |
| Labeling Kit Included | Yes (4205 Basic DC Label Kit) | No |
Common Concerns Answered
Is the initial cost higher than simpler fuse blocks?
While the upfront investment for the Blue Sea 1450 DC 8 Position CLB Square may be higher than basic fuse blocks, its integrated resettable circuit breakers and higher system amperage capacity offer long-term value and enhanced protection, reducing the need for frequent fuse replacements.
Will the included label kit cover all my custom installation needs?
The included 4205 Basic DC Label Kit provides essential labels for common marine circuits. For highly specialized or custom installations, additional labeling solutions may be required to ensure comprehensive circuit identification.
Why choose resettable breakers over fuses?
Resettable circuit breakers, like those included in this panel, automatically disengage upon overload and can be manually reset, providing a more convenient and durable solution compared to fuses which require replacement after activation.
Frequently Asked Questions
What is the maximum amperage rating for the Blue Sea 1450 DC 8 Position CLB Square?
The Blue Sea 1450 DC 8 Position CLB Square has a maximum system amperage rating of 90A.
What type of circuit breakers are included with the Blue Sea 1450 DC 8 Position CLB Square?
This panel includes eight 15A push-button reset only quick connect circuit breakers (model 7056).
What are the dimensions of the Blue Sea 1450 DC 8 Position CLB Square?
The dimensions of the panel are 4.75 inches in height, 4.88 inches in width, and 3.50 inches in depth.
Is the Blue Sea 1450 DC 8 Position CLB Square suitable for 12V and 24V DC systems?
Yes, the Blue Sea 1450 DC 8 Position CLB Square is designed for use with both 12V DC and 24V DC nominal voltage systems.
What is included in the Blue Sea 1450 DC 8 Position CLB Square package?
The package includes the 8-position DC circuit breaker panel, eight 15A push-button reset circuit breakers, and the 4205-Square Format Label Set.
