Blue Sea 3118 ELCI Panel Enclosure | Boat Supply Store
Protect your vessel's 120V AC electrical system from ground faults with this robust panel enclosure. Engineered to house an integrated 50A ELCI main breaker and two additional breakers, it ensures compliance with ABYC E-11 standards when installed near the shore power inlet. The enclosure measures 7.6" H x 7.4" W x 4.7" D, offering a durable glass-filled polycarbonate construction and a clear, watertight cover essential for the harsh marine environment found in offshore fishing vessels operating in the Gulf of Mexico.
Key Features
- Compliant Protection Meets ABYC E-11 standards when used with an ELCI main breaker.
- Integrated Safety Houses a 50A ELCI main breaker for essential equipment leakage protection.
- Customizable Configuration Includes 2 blank apertures for additional breaker installations.
- Durable Construction Features a glass-filled polycarbonate base for superior impact resistance.
- Watertight Seal Oversized, formed-in-place PUR gasket ensures superior protection against water ingress.
- Clear Visibility Clear cover allows for immediate visual confirmation of breaker status.
- Easy Installation Removable stainless steel hinge pin and secure stainless steel latch simplify mounting.
- Versatile Breaker Support Blank positions accommodate Carling Technologies™ A and C Series breakers.
Specifications
| Product Specifications | |
|---|---|
| 120V AC | Yes |
| 50A ELCI main breaker capacity | Yes |
| 2 blank spaces | Yes |
| Material | Glass-filled polycarbonate base, clear cover |
| Overall dimensions | 7.6" H x 7.4" W x 4.7" D |
| Enclosure internal dimensions | 6" H x 6" W x 4" D |
| Waterproof glands | Included |
| LED indicators | Included |
Who This Is For
Marine electricians and boat builders requiring a compliant and robust enclosure for 120V AC systems that integrates ELCI protection. Boat owners seeking to upgrade or ensure the safety and reliability of their onboard electrical panel configurations.
How It Compares
| Feature | Blue Sea 3118 ELCI Panel Enclosure | Competitor |
|---|---|---|
| ELCI Main Breaker Included | Yes (50A) | No, No |
| Blank Circuit Positions | 2 | 2, 12 |
| Material | Glass filled polycarbonate base, clear cover | Glass filled polycarbonate base, clear cover, Powder coated aluminum |
| Dimensions (Overall H x W x D) | 7.6" x 7.4" x 4.7" | 7.6" x 7.4" x 4.7", 12.5" x 10.5" x 5.5" |
| ABYC E-11 Compliance (with ELCI) | Yes | No (requires separate ELCI), No |
Common Concerns Answered
Why is the Blue Sea 3118 enclosure more expensive than basic panel boxes?
The higher price point is attributed to its integrated 50A ELCI main breaker, which provides essential ground fault protection, and the use of premium, durable materials like glass-filled polycarbonate and a robust seamless gasket, ensuring superior longevity and safety in marine applications.
What if I don't need an ELCI breaker?
While this enclosure is specifically designed for ELCI compliance, Blue Sea Systems offers the 3117 model which is a similar enclosure without the integrated ELCI, providing flexibility for systems where a separate ELCI solution is preferred or already in place.
Is the instruction manual comprehensive?
Some users have noted the included instruction manual is brief. However, Blue Sea Systems provides a detailed product manual accessible online via the provided URL, offering comprehensive installation guidance and technical specifications for optimal setup.
Frequently Asked Questions
What is the amperage rating of the ELCI breaker in the Blue Sea 3118 enclosure?
The Blue Sea 3118 SMS Panel Enclosure is designed to accommodate a 50A ELCI main breaker.
What are the overall dimensions of the Blue Sea 3118 SMS Panel Enclosure?
The overall dimensions of the Blue Sea 3118 enclosure are 7.6 inches in height, 7.4 inches in width, and 4.7 inches in depth.
Does the Blue Sea 3118 enclosure meet ABYC E-11 standards?
Yes, the Blue Sea 3118 enclosure meets ABYC E-11 standards when it is used in conjunction with an ELCI main circuit breaker and is mounted within 10 feet of the AC shore power inlet.
What type of circuit breakers can be installed in the blank apertures of the Blue Sea 3118 enclosure?
The blank circuit positions in the Blue Sea 3118 enclosure are designed to accommodate Carling Technologies™ A and C Series Flat Rocker and ELCI Main circuit breakers.
What is included in the box with the Blue Sea 3118 enclosure?
The Blue Sea 3118 enclosure includes the panel enclosure with a clear cover, two blank apertures, waterproof glands, and LED lights for backlighting and ON indication. The ELCI main breaker itself is typically purchased separately or as part of a kit if specified.
