Blue Sea 4308 WeatherDeck Fuse Panel | Boat Supply Store
For vessels with exposed helm stations, this 8-position fuse panel ensures reliable circuit protection against harsh marine conditions. Its IP67 rating guarantees submersion resistance, ideal for flybridge or open cockpit installations where water ingress is a primary concern. The panel operates at 12v DC, supporting up to 15A per circuit with a 100A panel cumulative limit, and features bicolored LEDs for immediate circuit status indication, alongside independent backlighting for enhanced nighttime visibility.
Key Features
- Superior IP67 Water Resistance for critical components in exposed environments.
- Intuitive Bicolored LEDs clearly indicate ON (Green), OFF (Red), or Blown (No Color) circuit status.
- Independent Backlighting Circuit allows for remote switching and dimming, enhancing nighttime control.
- Designed for Exposed Helm Stations including flybridges and open cockpits.
- ATO/ATC Fuse Protection offers standard, readily available circuit safety.
- Robust Construction built to withstand demanding marine conditions.
- Versatile Mounting Options with ability to mount in four different orientations.
- Enhanced Visibility with dedicated backlighting for easy identification in low light.
Specifications
| Product Specifications | |
|---|---|
| Positions | 8 |
| Voltage | 12v DC |
| Water Resistance Rating | IP67 |
| Fuse Type | ATO/ATC |
| Max Amperage per Circuit | 15A |
| Max Panel Amperage | 100A |
| LED Indicators | Bicolored (Red/Green/None) |
| Backlighting | Independent circuit |
| Dimensions | 7.7" H x 3.88" W x 2.5" D |
Who This Is For
Boaters operating vessels with helm stations directly exposed to the elements, such as flybridges or open cockpits. It is designed for individuals requiring dependable, water-resistant electrical distribution and circuit protection in a challenging marine environment.
How It Compares
| Feature | Blue Sea 4308 WeatherDeck Fuse Panel | Competitor |
|---|---|---|
| Waterproof Rating | IP67 | Not specified |
| Positions | 8 | 6 |
| Max Amperage per Circuit | 15A @ 12v DC | 30A |
| Circuit Status Indicators | Bicolored LEDs (Red/Green/None) | Typically less capable |
| Backlighting | Independent circuit | Typically less capable |
Common Concerns Answered
Will the Blue Sea 4308 withstand direct water exposure on my boat?
Yes, the Blue Sea 4308 features an IP67 rating, meaning its panel front is protected against dust ingress and immersion in water up to 1 meter for 30 minutes when properly mounted with its watertight gasket, making it suitable for exposed cockpit applications.
Can I power high-draw accessories with the 15A per circuit limit?
The 15A per circuit limit is designed for typical marine accessories. For higher-draw devices, you may need to split circuits or consider a panel with a higher amperage rating per circuit, but for most auxiliary systems, this limit is sufficient and provides individual circuit protection.
Are the included labels specific enough for my setup?
While the included labels cover common functions, users have found them to be generic. Additional custom labeling may be beneficial for highly specific or complex electrical configurations.
Frequently Asked Questions
Is the Blue Sea 4308 panel truly waterproof for open cockpit applications?
The Blue Sea 4308 is IP67 rated, signifying it is protected against dust and immersion in water up to 1 meter for 30 minutes when properly installed with the watertight gasket, making it highly suitable for exposed marine environments.
What is the maximum amperage per circuit for the Blue Sea 4308 fuse panel?
The maximum recommended amperage per circuit for the Blue Sea 4308 WeatherDeck Fuse Panel is 15A. The panel has a cumulative capacity of 100A.
How does the bicolored LED system indicate circuit status on the Blue Sea 4308?
The bicolored LEDs provide clear visual feedback: Green indicates the circuit is ON and functioning correctly, Red indicates the circuit is OFF, and no color illumination signifies that the fuse has blown.
Can the Blue Sea 4308 fuse panel be used with 24v DC systems?
No, the Blue Sea 4308 is designed and rated exclusively for 12v DC systems. Using it with higher voltage systems will result in damage and void the warranty.
What type of fuses does the Blue Sea 4308 use?
The Blue Sea 4308 utilizes standard ATO/ATC blade fuses, which are widely available and easily replaceable in the marine industry.
