Blue Sea MAXI Fuse Block 30-80A Ignition Protected | Boat Supply Store
Protect vital electrical systems from hazardous arcing with this ignition-protected fuse block designed for demanding marine environments. It accepts MAXI fuses rated from 30 to 80 amps, ensuring robust overcurrent protection for critical circuits on vessels navigating offshore or through fuel-rich atmospheres. The block accommodates wire sizes from 18 to 4 AWG, offering flexibility for installations and supporting substantial current draw.
Key Features
- Ignition Protected for safe operation in potentially explosive atmospheres
- 80A Maximum Rating supports high-draw circuits
- Accepts 4 AWG Wire for robust electrical connections
- Versatile Wiring Options adapt to tight spaces
- Label Recess for clear circuit identification
- Robust Marine-Grade Construction for durability
- 30-80A Range accommodates various protection needs
- Simplified Installation with #10 screw mounting
Specifications
| Product Specifications | |
|---|---|
| Brand | Blue Sea Systems |
| MPN | 5006100 |
| Model | MAXI Fuse Block |
| Amperage Range | 30-80A |
| Maximum Amperage | 80A |
| Maximum Voltage | 32V DC |
| Wire Gauge Accepted | 18-4 AWG |
| Mounting Screw Size | #10 |
Who This Is For
This fuse block is essential for marine enthusiasts and professional boat builders requiring a reliable, ignition-protected solution for managing circuits up to 80 amps. It is ideal for DIYers and installers needing to safeguard electrical systems on vessels operating in sensitive marine environments.
How It Compares
| Feature | Blue Sea MAXI Fuse Block 30-80A Ignition Protected | Competitor |
|---|---|---|
| Max Amperage | 80A | 100A, 100A |
| Ignition Protected | Yes | Varies by model, Varies by model |
| Max Voltage | 32V DC | 32V DC, 32V DC |
| Wire Size Accepted | 18-4 AWG | Up to 4 AWG, Up to 4 AWG |
| Wiring Orientation | Versatile | Standard, Standard |
Common Concerns Answered
Why is this fuse block more expensive than some others?
The higher price point reflects its critical ignition protection feature, crucial for safe operation in hazardous marine environments where fuel vapors may be present. This safety certification significantly enhances reliability compared to non-ignition protected alternatives.
Are MAXI fuses readily available in the necessary ratings?
MAXI fuses are a standard automotive and marine product, and while availability can fluctuate, most common ratings, including those for 30-80A circuits, are widely stocked by marine electrical suppliers.
Can I use this on older boats?
Yes, this fuse block is designed to upgrade or replace existing electrical protection systems on any vessel, especially where enhanced safety measures like ignition protection are required for compliance or operational security.
Frequently Asked Questions
What is the maximum amperage rating for the Blue Sea 5006100 MAXI Fuse Block?
The Blue Sea 5006100 MAXI Fuse Block has a maximum amperage rating of 80A.
What wire gauge can be used with this fuse block?
This fuse block accepts wire sizes ranging from 18 AWG to 4 AWG.
Is this fuse block ignition protected?
Yes, the Blue Sea 5006100 MAXI Fuse Block is ignition protected, making it safe for use in potentially explosive marine atmospheres.
What is the maximum DC voltage this fuse block can handle?
This fuse block is designed to handle a maximum DC voltage of 32V.
What type of screws are needed for mounting this fuse block?
Mounting this fuse block requires #10 screws.
