Blue Sea 100A ANL Fuse | Boat Supply Store
Safeguard critical DC circuits on your vessel against overcurrent events with this ignition-protected ANL fuse. Engineered for marine environments, it provides robust protection for main battery banks, essential for gasoline-powered boats where preventing ignition of flammable vapors is paramount. With a high 6,000 AIC rating and silver-plated blades for superior corrosion resistance, this 100 Amp fuse ensures reliable performance and safety even under demanding conditions.
Key Features
- 100 Amp high-capacity DC circuit protection.
- Ignition Protected conforming to SAE J1171 for safe use on gasoline vessels.
- Silver-plated blades ensure superior corrosion resistance in marine environments.
- Visible blown indication allows for quick identification of a tripped fuse.
- 6,000 Ampere Interrupt Capacity (AIC) provides substantial fault current protection.
- Designed for ANL Fuse Blocks for a secure and dedicated installation.
- Trusted Blue Sea Systems brand ensures marine-grade reliability.
- Durable construction built to withstand harsh maritime conditions.
Specifications
| Product Specifications | |
|---|---|
| Ampere Rating | 100A |
| Fuse Type | ANL |
| Ignition Protected | Yes (SAE J1171) |
| AIC Rating | 6,000A |
| Connector Blades | Silver-plated |
| Visible Blown Indication | Yes |
Who This Is For
Boat owners and marine technicians requiring dependable DC circuit protection, especially for main battery banks on gasoline-powered vessels where ignition protection is a critical safety requirement.
How It Compares
| Feature | Blue Sea 100A ANL Fuse | Littelfuse ANL100 |
|---|---|---|
| Amperage | 100A | 100A |
| Fuse Type | ANL | ANL |
| Ignition Protected | Yes (SAE J1171) | Not Specified |
| AIC Rating | 6,000A | 2,000A |
| Connector Blades | Silver-plated | Not Specified |
| Visible Blown Indication | Yes | Not Specified |
Common Concerns Answered
Is the initial cost of this fuse higher than generic alternatives?
While the upfront cost may be higher than non-marine specific fuses, the Blue Sea 5125 ANL Fuse justifies the investment with its critical safety features, including SAE J1171 ignition protection and a superior 6,000 AIC rating, essential for marine applications.
Are specific amperage ratings readily available?
Availability of specific amperage ratings can vary, but this 100A version is a standard offering from Blue Sea Systems, designed to meet the demands of most primary battery bank protection requirements.
Why choose a marine-specific fuse over a general-purpose one?
Marine-specific fuses like the Blue Sea 5125 are built with materials and certifications, such as SAE J1171 ignition protection, to withstand corrosive environments and prevent hazardous conditions like explosions in gasoline-powered engine compartments, offering a crucial safety advantage.
Frequently Asked Questions
What is the amperage rating of the Blue Sea 5125 ANL Fuse?
The Blue Sea 5125 ANL Fuse has a 100 Ampere rating.
Is the Blue Sea 5125 ANL Fuse ignition protected?
Yes, the Blue Sea 5125 ANL Fuse is ignition protected and conforms to SAE J1171 standards.
What is the AIC rating of the Blue Sea 5125 ANL Fuse?
The AIC (Ampere Interrupt Capacity) rating of the Blue Sea 5125 ANL Fuse is 6,000 Amperes.
What type of fuse block is the Blue Sea 5125 ANL Fuse designed for?
This fuse is designed for use with Blue Sea Systems ANL Fuse Blocks.
Does the Blue Sea 5125 ANL Fuse have a visible indication of a blown condition?
Yes, the Blue Sea 5125 ANL Fuse features a visible indication of a blown condition.
