Blue Sea 7236 Double Pole Toggle 20A | Boat Supply Store
Safeguard critical AC main circuits on your vessel with the Blue Sea 7236 A-Series Double Pole Toggle circuit breaker, rated for 20A. This unit integrates essential switching and protection functions, meeting stringent ABYC standards and featuring a 'trip-free' design that prevents manual closure during fault conditions for enhanced safety. Essential for maintaining reliable power distribution on any vessel operating in demanding marine environments, from the Gulf Coast to the Great Lakes.
Key Features
- Double Pole operation for simultaneous control of two circuits.
- 20A Amperage Rating suitable for primary AC loads.
- 'Trip Free' Design ensures circuit protection during fault conditions.
- ABYC Standards Compliant for marine application safety.
- UL 1077 Recognized for auxiliary protective device applications.
- TUV, CE, and CSA Certified for global compliance.
- Integrated Switching and Protection simplifies panel layout.
- Black Toggle Actuator for clear visual status indication.
Specifications
| Product Specifications | |
|---|---|
| Brand | Blue Sea Systems |
| Model | 7236 A-Series |
| Poles | Double Pole |
| Amperage Rating | 20A |
| Color | Black |
| Mounting Style | Panel Mount |
| Terminal Type | Solderless |
| Actuator Type | Toggle |
| Certifications | ABYC, UL 1077, TUV, CE, CSA |
Who This Is For
Marine electricians and boat owners requiring certified AC main circuit protection and switching for their vessels. Boat builders will find this unit ideal for panel integration and ensuring compliance with safety standards.
How It Compares
| Feature | Blue Sea 7236 Double Pole Toggle 20A | Blue Sea Systems 7237 A |
|---|---|---|
| Amperage | 20A | 30A, 20A |
| Poles | 2 | 2, 2 |
| Certifications | ABYC, UL 1077, TUV, CE, CSA | ABYC, UL 1077, TUV, CE, CSA, Varies by specific model, often UL Recognized, CSA Certified |
| Trip Free Design | Yes | Yes, Yes |
Common Concerns Answered
Is the price higher than generic options?
While the initial investment for the Blue Sea 7236 may exceed generic breakers, its comprehensive certifications (ABYC, UL 1077, TUV, CE, CSA) and critical 'trip-free' safety feature provide superior reliability and peace of mind, justifying the cost for critical marine electrical systems.
Is installation complicated for a DIYer?
The Blue Sea 7236 has an Install Difficulty rating of 3, requiring basic electrical knowledge and proper tools. For optimal safety and system integrity, it is recommended for those familiar with marine electrical systems or to be installed by a qualified marine electrician.
Can the toggle be difficult to operate?
While occasional feedback on toggle stiffness can occur with mechanical switches, the Blue Sea 7236 is engineered for robust performance. Customers generally report high satisfaction with the reliability and positive tactile feedback of Blue Sea Systems products.
Frequently Asked Questions
What is the amperage rating of the Blue Sea 7236 A-Series Double Pole Toggle?
The Blue Sea 7236 A-Series Double Pole Toggle has an amperage rating of 20A.
What certifications does the Blue Sea 7236 A-Series Double Pole Toggle have?
The Blue Sea 7236 A-Series Double Pole Toggle holds multiple certifications including ABYC, UL 1077 recognized, TUV certified, CE marked, and CSA certified.
Can the Blue Sea 7236 A-Series Double Pole Toggle be held ON during a fault current condition?
No, the Blue Sea 7236 features a 'Trip Free' design, meaning it cannot be manually held in the ON position during a fault current condition, ensuring proper circuit protection.
What is the purpose of the 'Trip Free' design on this circuit breaker?
The 'Trip Free' design is a crucial safety feature that prevents the breaker from being manually held closed when a fault current is present, thereby protecting the circuit and equipment from damage.
Is this circuit breaker suitable for AC main circuit protection?
Yes, the Blue Sea 7236 is specifically designed for AC main circuit protection and switching applications on vessels.
