Blue Sea 7765 Solenoid Switch - 150A | Boat Supply Store
For critical DC load management in demanding marine environments, this 150A solenoid switch ensures reliable operation. It is engineered for 12/24V DC systems and features hermetically sealed contacts, providing superior protection against moisture and corrosion. The low-draw coil control circuit minimizes power consumption, making it an efficient solution for switching high-demand equipment such as windlasses or thruster systems on offshore fishing boats.
Key Features
- Continuous duty rating for sustained operation.
- SPST - Normally Open configuration for straightforward circuit control.
- Hermetically sealed contacts prevent environmental ingress and ensure longevity.
- Remote activation via a separate ON-OFF switch for flexible installation.
- Low-draw coil circuit minimizes power consumption and heat generation.
- Ideal for switching subpanels, thrusters, windlasses, and inverters.
- Robust construction designed for harsh marine conditions.
- Supports 12/24V DC systems for versatility.
Specifications
| Product Specifications | |
|---|---|
| Brand | Blue Sea Systems |
| Model | 7765 L-Series |
| Amperage Rating | 150A Continuous Duty |
| Voltage System | 12/24V DC |
| Configuration | SPST - Normally Open |
| Contact Type | Hermetically Sealed |
| Activation | Remote ON-OFF switch (sold separately) |
| SKU | CWR90404 |
| BC_ID | 142827 |
| MPN | 7765 |
Who This Is For
Boat owners and marine technicians requiring a robust and reliable solenoid switch for managing medium to high-amperage DC loads in 12V or 24V systems. It is specifically designed for critical applications like thrusters, windlasses, and inverters.
How It Compares
| Feature | Blue Sea 7765 Solenoid Switch - 150A | Model 1120 |
|---|---|---|
| Continuous Amperage Rating | 150A | 100A, 100A |
| Voltage System | 12/24V DC | 12V DC, 12/24V DC |
| Configuration | SPST - Normally Open | SPST - Normally Open, SPST - Normally Open |
| Contact Type | Hermetically Sealed | Sealed, Sealed |
| Remote Activation | Requires separate ON-OFF switch (8230) | Requires separate switch, Requires separate switch |
Common Concerns Answered
Does the solenoid come with the necessary remote switch?
No, the Blue Sea 7765 L-Series Solenoid Switch requires a separate remote ON-OFF switch, such as the Blue Sea 8230, which must be purchased in addition to the solenoid unit. This allows for flexible placement of the control switch.
Is this solenoid switch cost-effective?
While the initial investment for the Blue Sea 7765 L-Series Solenoid Switch may be higher than some lower-amperage or less robust alternatives, its 150A rating, hermetically sealed contacts, and continuous duty capability provide superior long-term reliability and performance for critical loads, justifying the price for demanding applications.
Why choose a hermetically sealed solenoid?
The hermetically sealed contacts in the Blue Sea 7765 L-Series Solenoid Switch provide enhanced durability by protecting the electrical connection points from moisture, salt spray, dust, and corrosive elements common in marine environments. This significantly reduces the risk of contact degradation and failure.
Frequently Asked Questions
What is the continuous duty rating of the Blue Sea 7765 L-Series Solenoid Switch?
The Blue Sea 7765 L-Series Solenoid Switch has a continuous duty rating of 150 Amperes.
What voltage systems is the Blue Sea 7765 L-Series Solenoid Switch compatible with?
This solenoid switch is compatible with both 12V DC and 24V DC electrical systems.
What type of switch is the Blue Sea 7765 L-Series Solenoid Switch (SPST, SPDT, etc.)?
The Blue Sea 7765 L-Series Solenoid Switch is a Single Pole, Single Throw (SPST) configuration, specifically designed to be Normally Open (NO).
Does the Blue Sea 7765 L-Series Solenoid Switch come with a remote ON-OFF switch?
No, the Blue Sea 7765 L-Series Solenoid Switch is activated by a remote ON-OFF switch which is sold separately.
What are some common applications for the Blue Sea 7765 L-Series Solenoid Switch?
Common applications include switching DC subpanels, thrusters, windlasses, inverters, and other medium- to high-amperage DC loads in marine applications.
