Blue Sea 8025 DC 3-Pos Breaker Panel | Boat Supply Store
Efficiently manage up to three independent DC battery banks and associated circuits with the Blue Sea 8025 3-Position DC Breaker Panel. This system is engineered for 12V/24V DC applications, handling a maximum continuous current of 100A. Its compact 3.75" height and 5.25" width make it suitable for console or bulkhead mounting, ensuring a clean and organized electrical distribution, essential for offshore fishing vessels on the Gulf Coast.
Key Features
- Pre-wired buses for simplified DC system integration.
- Backlit label positions enhance readability in low light conditions.
- Indicator LEDs provide immediate ON status for each circuit.
- 100A maximum continuous system rating ensures robust power handling.
- Upgradable to 24V operation with appropriate meter conversion.
- Includes three 15A single-pole toggle circuit breakers for immediate use.
- UL 1500 and SAE J1171 certified for marine environment safety.
- Compact dimensions of 3.75" H x 5.25" W for versatile installation.
Specifications
| Product Specifications | |
|---|---|
| Positions | 3 |
| Voltage | 12V / 24V DC |
| Maximum Amperage | 100A |
| Height | 3.75" |
| Width | 5.25" |
| Included Circuit Breakers | 3 x 15A Single Pole Toggle |
| Labeling | Backlit circuit label positions |
| Indicator Lights | ON indicating LEDs installed in all circuit positions |
| Certifications | UL 1500 | SAE J1171 |
Who This Is For
Boat owners and marine technicians requiring a highly organized and pre-wired DC power management solution for up to three battery banks. This panel is suitable for both 12V and 24V DC systems on vessels needing reliable circuit protection and clear status indication.
How It Compares
| Feature | Blue Sea 8025 DC 3-Pos Breaker Panel | Blue Sea Systems 8026 DC 6 Position Breaker Panel |
|---|---|---|
| Positions | 3 | 6, 9 |
| Maximum Amperage | 100A | 100A, 100A |
| Nominal Voltage | 12v / 24v DC | 12v / 24v DC, 12v / 24v DC |
| Included Circuit Breakers | (3) 15A Single Pole Toggle | 6 x 15A Single Pole Toggle, 9 x 15A Single Pole Toggle |
| Backlit Labels | Yes | Yes, Yes |
Common Concerns Answered
What if the included 15A breakers are insufficient for my high-draw accessories?
The Blue Sea 8025 panel is designed to accept standard marine circuit breakers, allowing you to easily replace the included 15A breakers with higher amperage, single-pole toggle breakers as required for specific high-draw applications, ensuring adequate protection without compromising system integrity.
Is this panel too large for smaller boats?
With dimensions of 3.75 inches in height and 5.25 inches in width, this panel is relatively compact. However, for extremely limited space installations, verify the available mounting area against these specifications to ensure proper fitment.
Why does this panel cost more than simpler options?
The Blue Sea 8025 panel offers significant value through its fully pre-wired positive, negative, and ground buses, integrated backlit labels, and ON indicator LEDs, which drastically reduce installation time and improve operational clarity compared to basic switch panels, justifying the investment for a professional marine electrical setup.
Frequently Asked Questions
What is the maximum amperage for the Blue Sea 8025 DC 3 Position Breaker Panel?
The Blue Sea 8025 DC 3 Position Breaker Panel is rated for a maximum continuous amperage of 100A.
Can this panel be used for both 12V and 24V DC systems?
Yes, this panel is designed to operate within both 12V and 24V DC marine electrical systems. It is owner upgradable to 24V operation with specific meter conversions.
What type of circuit breakers are included with this panel?
The panel includes three 15A single-pole toggle circuit breakers.
Is this panel suitable for upgrading to 24-volt systems?
Yes, the Blue Sea 8025 panel is owner upgradable to 24-volt systems, provided you are using panels with analog meters and utilize the appropriate upgrade kits (8240 or 8243 for 18-32V DC meters).
Does the panel have backlit circuit label positions?
Yes, the standard panels feature backlit circuit label positions, requiring no additional kit for illumination.
