Blue Sea 8032 AC Toggle Source Selector | Boat Supply Store
Securely manage dual 120V AC power sources on your vessel with the Blue Sea 8032 AC Toggle Source Selector. This unit incorporates double pole 30A circuit breakers with integrated lockout slides, effectively preventing simultaneous connection of shore power and generator circuits. It features fully pre-wired hot, neutral, and ground buses, along with a red reverse polarity LED for immediate visual confirmation of correct wiring.
Key Features
- Prevents simultaneous connection of both AC sources via integrated lockout slide.
- Protects circuits with two 30A double pole AC main circuit breakers.
- Illuminates circuit positions with integrated backlit labels for clear identification.
- Indicates proper polarity with a red reverse polarity LED.
- Simplifies installation with fully pre-wired hot, neutral, and safety ground buses.
- Provides clear status indication with "ON" LEDs for each circuit.
- Ensures reliable operation with a maximum panel amperage of 50A.
- Offers robust construction from Blue Sea Systems for marine environments.
Specifications
| Product Specifications | |
|---|---|
| Nominal Voltage | 120v AC |
| Source Selection | 2 |
| Amperage Rating | 30A per breaker |
| Maximum Panel Amperage | 50A |
| Circuit Breaker Type | Double Pole AC |
| Reverse Polarity Indicator | Yes (Red LED) |
| Backlit Labels | Yes |
| Pre-wired Buses | Yes (Hot, Neutral, Ground) |
| Lockout Feature | Yes (Slide) |
Who This Is For
Marine electricians and vessel owners requiring a reliable and safe method to switch between two distinct 120V AC power sources. This selector is ideal for boats with both shore power inlets and onboard generators needing safe and compliant power management.
How It Compares
| Feature | Blue Sea 8032 AC Toggle Source Selector | Competitor |
|---|---|---|
| Source Selection | 2 | 2, 4 |
| Integrated Circuit Breakers | Yes (2x 30A Double Pole) | Yes (2x 30A Double Pole), No |
| Simultaneous Source Connection Prevention | Yes (Lockout Slide) | Yes (Lockout Slide), No |
| Backlit Labels | Yes | Yes, No |
| Reverse Polarity LED | Yes (Red) | Yes (Red), No |
Common Concerns Answered
Is the Blue Sea 8032 selector switch a significant investment compared to simpler options?
While the initial cost may be higher than basic selector switches, the Blue Sea 8032 offers integrated double pole circuit breakers, a lockout slide for preventing simultaneous source connection, a reverse polarity LED, and backlit labels, providing substantial safety and operational value that justifies the investment for critical AC power management.
Will this unit require substantial custom panel modifications for installation?
The Blue Sea 8032 requires a dedicated panel space for proper installation, but its pre-wired buses and clear labeling are designed to streamline the process, minimizing complex wiring tasks for marine electricians.
Can this selector switch handle high electrical loads common on larger vessels?
This selector switch is rated for 30A per circuit breaker and a maximum panel amperage of 50A, making it suitable for managing typical 120V AC loads on recreational vessels where simultaneous source connection must be prevented.
Frequently Asked Questions
What is the maximum amperage this Blue Sea 8032 AC Toggle Source Selector can handle?
The Blue Sea 8032 AC Toggle Source Selector features two 30A double pole circuit breakers and has a maximum panel amperage of 50A.
Can this selector prevent connecting both AC sources simultaneously?
Yes, the Blue Sea 8032 is equipped with an integrated lockout slide specifically designed to prevent simultaneous connection of both AC sources.
What voltage does the Blue Sea 8032 AC Toggle Source Selector operate on?
The Blue Sea 8032 AC Toggle Source Selector operates on a nominal voltage of 120V AC.
What is included with the Blue Sea 8032 AC Toggle Source Selector?
The Blue Sea 8032 includes two 30A A-Series white toggle circuit breakers, a label set, green and red LEDs, and fully pre-wired hot, neutral, and safety ground buses.
Does this product come with backlit labels for circuit positions?
Yes, all circuit label positions on the Blue Sea 8032 are backlit, eliminating the need for an additional kit for clear circuit identification.
