Blue Sea 8074 AC Panel | Boat Supply Store
For offshore cruisers and coastal sailors demanding robust 120V AC system control, this pre-wired panel eliminates complex wiring tasks. It features an integrated 0-150 Volt AC Voltmeter and a 0-50 Amp AC Ammeter for comprehensive real-time system monitoring. The unit comes factory-equipped with one 30A double pole and five 15A single pole circuit breakers, ensuring immediate protection for essential AC circuits.
Key Features
- Integrated Voltmeter and Ammeter for real-time monitoring.
- Pre-wired hot, neutral, and ground buses simplify installation.
- Reverse Polarity indicating LED enhances safety during connection.
- Backlighting for labels ensures visibility in low-light conditions.
- UL Listed for confirmed safety and quality standards.
- Comprehensive breaker selection included for immediate use.
- Robust construction from Blue Sea Systems, a trusted marine brand.
- Efficient panel layout for 8 positions on a 120V AC system.
Specifications
| Product Specifications | |
|---|---|
| Brand | Blue Sea Systems |
| Model | 8074 |
| Positions | 8 |
| Switch Type | Toggle |
| Color | White |
| Voltage | 120V AC |
| Maximum Amperage | 50A |
| Voltmeter | 0-150 Volt AC (9353) |
| Ammeter | 0-50 Amp AC (9630) |
| Included Breakers | 1 x 30A Double Pole, 5 x 15A Single Pole |
| Bus Bars | Pre-installed Hot, Neutral, and Ground |
| Indicators | Reverse Polarity LED, Label Backlighting, All LEDs Installed |
| Safety Certification | UL Listed |
Who This Is For
Marine electricians and discerning boat owners seeking a meticulously engineered and pre-wired AC main distribution panel for 120-volt systems. This unit is ideal for vessels where precise electrical monitoring and simplified installation are paramount.
How It Compares
| Feature | Blue Sea 8074 AC Panel | Blue Sea Systems 8263 AC Main Circuit Breaker Panel |
|---|---|---|
| Number of Positions | 8 | 8 |
| Integrated Voltmeter | Yes (0-150V AC) | No |
| Integrated Ammeter | Yes (0-50A AC) | No |
| Pre-wired Bus Bars | Yes (Hot, Neutral, Ground) | Yes |
| Max Panel Amperage | 50A | 50A |
| Voltage | 120V AC | 120V AC |
Common Concerns Answered
Is the installation process straightforward for a novice?
While this panel is pre-wired with bus bars, connecting shore power, generator inputs, and individual circuits still requires a solid understanding of AC marine electrical systems and safety protocols. Professional installation is recommended if you are not experienced with marine electrical work.
Why is this panel more expensive than simpler alternatives?
The higher price point reflects the integrated voltmeter and ammeter, pre-installed backlighting, and the overall quality and reputation of Blue Sea Systems for robust marine electrical components. These features provide advanced monitoring and reduce installation complexity compared to basic panels.
What if I'm unsure about the electrical knowledge required?
The installation difficulty is rated as Moderate (3). Due to the complexities of AC marine electrical systems, including safety protocols and proper terminations, we strongly recommend professional installation for those unfamiliar with this type of work to ensure safety and system integrity.
Frequently Asked Questions
What is the maximum amperage this panel can handle?
This Blue Sea 8074 AC Main circuit breaker panel has a maximum panel amperage rating of 50 Amperes.
What types of circuit breakers are included with this panel?
The panel includes one 30A double pole circuit breaker and five 15A single pole circuit breakers, all designed for 120 Volt operation.
Does this panel include a voltmeter and ammeter?
Yes, this panel comes with an integrated 0-150 Volt AC Voltmeter (part number 9353) and a 0-50 Amp AC Ammeter (part number 9630).
What voltage is this AC panel designed for?
This AC panel is specifically designed for 120 Volt AC operation.
What are the dimensions of the Blue Sea 8074 panel?
Please refer to the product manual or the Blue Sea Systems website for specific dimensional drawings, as dimensions are not provided in the basic specifications. The manual URL is: https://www.bluesea.com/products/8074/AC_Main_Circuit_Breaker_Panel_-_8_Positions_-_White_Switches
