Blue Sea 8385 DC 8 Position Horizontal Panel | Boat Supply Store
For vessels demanding organized and reliable DC power distribution, the Blue Sea 8385 provides a fully pre-wired solution. This 8-position horizontal panel operates at 12 VDC or 24 VDC and handles up to 100A, ensuring robust performance for offshore fishing boats or coastal cruisers. Its MIL-C-5541C undercoating and heavy 1/8" aluminum construction offer exceptional corrosion resistance for longevity in harsh marine environments.
Key Features
- Expandable 8-position horizontal configuration for flexible power management
- Versatile 12 VDC/24 VDC voltage rating suitable for most vessels
- High Capacity 100A amperage rating to support significant electrical loads
- Ready-to-Install fully pre-wired positive, negative, and grounding buses
- Future-Proof owner upgradable to 24 Volts with specific meters
- Clear Indication backlit circuit label positions and "ON" indicating LEDs
- Durable Construction MIL-C-5541C immersion undercoating for lifetime corrosion resistance
- Professional Finish two-part polyurethane slate gray finish on heavy 1/8" aluminum 5052 alloy
Specifications
| Product Specifications | |
|---|---|
| Positions | 8 |
| Configuration | Horizontal |
| Voltage Rating | 12 VDC/24 VDC |
| Amperage Rating | 100A |
| Buses | All positive, negative, and grounding buses installed, fully pre-wired |
| Backlit Labels | Yes |
| ON Indicating LEDs | Yes |
| Corrosion Resistance | MIL-C-5541C or equivalent immersion undercoating |
| Finish | Two-part polyurethane slate gray |
| Construction Material | Heavy 1/8" aluminum 5052 alloy |
| Mounting Holes | Countersunk |
| Included Labels | Set of 30 common Large Format Panel Labels |
Who This Is For
Marine enthusiasts and boat owners requiring a robust, organized, and expandable DC electrical distribution panel for vessels operating on 12V or 24V systems. Marine electricians will also benefit from the pre-wired nature and comprehensive features for efficient installations.
How It Compares
| Feature | Blue Sea 8385 DC 8 Position Horizontal Panel | Blue Sea Systems |
|---|---|---|
| Positions | 8 | 8 |
| Configuration | Horizontal | Vertical |
| Voltage | 12 VDC/24 VDC | 12 VDC/24 VDC |
| Amperage | 100A | 100A |
| Pre-wired Buses | All positive, negative, and grounding buses installed, fully pre-wired | All positive, negative, and grounding buses installed, fully pre-wired |
| Backlit Labels | Yes | Yes |
| ON Indicating LEDs | Yes | Yes |
| Corrosion Resistance | MIL-C-5541C or equivalent immersion undercoating | MIL-C-5541C or equivalent immersion undercoating |
Common Concerns Answered
Is the Blue Sea 8385 panel an expensive option?
While the initial investment for the Blue Sea 8385 may appear higher than basic distribution blocks, its comprehensive features including pre-wiring, integrated LED indicators, backlit labels, and superior corrosion resistance offer significant long-term value and simplify installation, making it a justifiable cost for demanding marine electrical systems.
What if the included label set doesn't cover my specific needs?
The Blue Sea 8385 includes a set of 30 common Large Format Panel Labels, designed to cover most standard applications. For highly specialized systems, the backlit label positions allow for easy customization and application of custom labels if needed.
Is this panel suitable for all types of vessels?
Yes, the Blue Sea 8385 is designed for a wide range of vessels operating on 12V or 24V DC systems, providing a robust and organized electrical distribution solution for everything from small center consoles to larger cruising yachts.
Frequently Asked Questions
What is the maximum voltage and amperage for the Blue Sea 8385 DC 8 Position Horizontal panel?
The Blue Sea 8385 DC 8 Position Horizontal panel supports a maximum of 24 VDC and has a 100A amperage rating.
Can the Blue Sea 8385 panel be upgraded to 24 volts?
Yes, the Blue Sea 8385 panel is owner upgradable to 24 Volts by utilizing specific meters such as the 8240 or 8243 (18-32V DC meters).
Does the Blue Sea 8385 panel come with labels?
Yes, the Blue Sea 8385 panel includes a set of 30 common Large Format Panel Labels for labeling your circuits.
What is the corrosion resistance of the Blue Sea 8385 panel?
The Blue Sea 8385 panel features MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance and has a durable two-part polyurethane slate gray finish.
What are the dimensions of the Blue Sea 8385 panel?
The Blue Sea 8385 panel is designed to industry standard height and width dimensions for easy integration into existing marine electrical panels.
