4 Pos Deutsch Connector Female Grey | Boat Supply Store
For critical marine electrical systems demanding unwavering integrity, this 4-position female Deutsch DT Series connector provides a robust, environmentally sealed solution. Engineered with a unique wedge lock mechanism, it ensures a vibration-resistant connection essential for offshore applications or high-impact fishing scenarios. This connector supports wire gauges from 20 to 14 AWG and maintains a continuous 13 Amp rating, guaranteeing reliable power distribution even in corrosive saltwater environments.
Key Features
- Superior Environmental Sealing for Harsh Marine Conditions
- Secure Vibration-Resistant Connection via Wedge Lock
- Reliable 4-Position Deutsch DT Series Female Plug
- Durable Construction for Long-Term Performance
- Versatile Wire Gauge Compatibility (20-14 AWG)
- Robust 13 Amp Current Rating
- Distinctive Grey Color for Easy Identification
- Compact Rectangular Form Factor
Specifications
| Product Specifications | |
|---|---|
| Number of Positions | 4 |
| Gender | Female |
| Series | DT |
| Shape | Rectangular |
| Color | Grey |
| Cavities | 4 |
| Contact Size | 16 |
| Current Rating | 13 Amps |
| Wire Gauge Compatibility | 20-14 AWG |
| Sealing | Environmentally Sealed |
| Locking Mechanism | Wedge Lock |
Who This Is For
Ideal for marine technicians, boat builders, and dedicated DIY boaters who require dependable, environmentally sealed electrical connections. This connector is essential for anyone undertaking repairs or installations in demanding marine environments where system failure is not an option.
How It Compares
| Feature | 4 Pos Deutsch Connector Female Grey | TE Connectivity Deutsch DT06 |
|---|---|---|
| Number of Positions | 4 | 4 |
| Gender | Female | Female |
| Series | DT | DT |
| Wire Gauge | 20-14 AWG | 20-14 AWG |
| Current Rating | 13 A | 13 A |
| Environmental Sealing | Yes | Yes |
Common Concerns Answered
Finding the correct male counterpart can sometimes be challenging. How do I ensure compatibility?
This is a standard Deutsch DT Series 4-position female connector (MPN: DT06-4S). Ensure your male counterpart is also a DT Series 4-position plug (MPN: DT04-4P) to guarantee a proper, intermateable connection.
What are the risks of crimping terminals incorrectly?
Improper crimping can lead to intermittent connections or outright failure, especially under vibration. Utilize a dedicated Deutsch DT Series crimping tool designed for Contact Size 16 terminals to ensure a secure, gas-tight electrical bond.
Why are these sealed connectors more expensive than non-sealed options?
The higher cost reflects the advanced engineering and materials required for superior environmental sealing and vibration resistance. This investment prevents corrosion, water ingress, and electrical failures, providing superior long-term reliability in harsh marine conditions.
Frequently Asked Questions
What is the wire gauge range this Deutsch connector can accommodate?
This connector is designed to accommodate wire sizes ranging from 20 to 14 AWG.
What is the maximum current rating for this connector?
The connector has a current rating of 13 Amps.
Is this connector designed to withstand marine environmental conditions?
Yes, this connector is environmentally sealed and built to withstand harsh marine conditions.
What does the 'wedge lock' feature signify?
The wedge lock is an internal component that, once the connector halves are mated, slides into place to mechanically lock the two halves together, significantly enhancing resistance to vibration and preventing accidental separation.
What is the physical color of this Deutsch connector?
This Deutsch connector is grey in color.
