Digital Yacht GPS160 TriNav Sensor | Boat Supply Store
Achieve precise and reliable offshore navigation with the Digital Yacht GPS160 TriNav Sensor, engineered to overcome the limitations of single-system GPS receivers. This unit simultaneously leverages GPS, Galileo, and Glonass satellite constellations, delivering sub 1-meter typical accuracy for critical positioning. With NMEA 0183 output at user-selectable baud rates up to 115200, it integrates seamlessly with PC-based navigation systems and older chartplotters, while also offering advanced Man Overboard (MOB) functionality for enhanced safety in challenging coastal waters.
Key Features
- Superior Positioning achieved by simultaneous GPS, Galileo, and Glonass satellite system utilization (TriNav technology).
- High Accuracy with sub 1-meter typical positioning, critical for precise course plotting.
- Flexible Configuration allowing field-programmable single GNSS operation (GPS, Glonass, or Galileo only).
- Programmable Baud Rates supporting user-selectable 4800, 38400, and 115200 baud for NMEA 0183 output.
- Enhanced Safety with support for an external MOB switch generating a synthetic AIS SART MOB message.
- Rapid Updates up to an 18Hz user-selectable update rate for real-time navigation data.
- Professional System Compatibility featuring datum sentence structure for ECDIS integration.
- Versatile Mounting with standard 1" x 14 TPI threaded mount compatibility for easy installation.
Specifications
| Product Specifications | |
|---|---|
| Receiver Type | 72-channel GNSS |
| Supported Constellations | GPS, Glonass, Galileo |
| Typical Accuracy | Sub 1m |
| NMEA 0183 Output | 4800, 38400, 115200 baud (programmable) |
| Maximum Update Rate | 18Hz |
| MOB Switch Support | Yes |
| System Support | Professional (ECDIS) |
| Mounting Compatibility | Standard 1" x 14 TPI thread |
Who This Is For
Mariners demanding superior positioning accuracy and redundancy, particularly those utilizing NMEA 0183 interfaces for PC navigation or older chartplotters. This sensor is also ideal for vessels prioritizing advanced safety features, including dedicated Man Overboard (MOB) detection and reporting.
How It Compares
| Feature | Digital Yacht GPS160 TriNav Sensor | Competitor |
|---|---|---|
| Satellite Systems | GPS, Glonass, Galileo | GPS, GLONASS, Galileo |
| Typical Accuracy | Sub 1m | < 3m |
| Primary Output | NMEA 0183 | NMEA 2000 |
| Update Rate | Up to 18Hz | 10Hz |
| MOB Functionality | Yes (synthetic AIS SART MOB) | No direct MOB output |
Common Concerns Answered
I need NMEA 2000 connectivity. Is the GPS160 compatible?
The Digital Yacht GPS160 TriNav Sensor outputs NMEA 0183 natively. For NMEA 2000 systems, you will require an additional converter such as the Digital Yacht iKonvert bundle to bridge the data.
Is the setup process straightforward?
While basic NMEA 0183 wiring is simple, specific configurations for baud rates or NMEA sentence output may require consulting the comprehensive manual for optimal system integration.
Will this sensor work with older chartplotters?
Yes, its NMEA 0183 output makes it highly compatible with a wide range of established marine electronics, including many chartplotters that may not feature NMEA 2000 connectivity.
Frequently Asked Questions
What satellite systems does the Digital Yacht GPS160 TriNav Sensor support?
The Digital Yacht GPS160 TriNav Sensor simultaneously supports GPS, Glonass, and Galileo satellite systems for enhanced positioning accuracy and reliability.
What is the typical accuracy of the Digital Yacht GPS160 TriNav Sensor?
The Digital Yacht GPS160 TriNav Sensor provides a typical accuracy of sub 1 meter.
Can the Digital Yacht GPS160 TriNav Sensor be configured for single GNSS operation?
Yes, the sensor is field programmable to operate with a single GNSS system, allowing you to select GPS, Glonass, or Galileo exclusively if desired.
What output baud rates are supported by the Digital Yacht GPS160 TriNav Sensor?
The Digital Yacht GPS160 TriNav Sensor supports user-selectable NMEA 0183 output baud rates of 4800, 38400, and 115200.
Does the Digital Yacht GPS160 TriNav Sensor support an external MOB switch?
Yes, the Digital Yacht GPS160 TriNav Sensor supports an external MOB switch, which generates a synthetic AIS SART MOB message for enhanced safety.
