Digital Yacht iSeaSense Wireless Speed Depth Temp Pack | Boat Supply Store
Modernize your vessel's data acquisition with integrated wireless and NMEA 2000 connectivity. This system provides critical metrics including depth up to 100m and boat speed with 5Hz updates. Gain insights into your vessel's performance with integrated pitch and heel sensors, crucial for precise sail trim or powerboat planing efficiency.
Key Features
- NMEA 2000 & Wireless WiFi connectivity for seamless integration and broad device compatibility.
- App-Free Web Interface eliminates the need for dedicated mobile applications, displaying data on any smart device browser.
- High-Accuracy Sensors deliver precise depth (100m), speed (0.3-45 knots), water temperature, and pitch/roll data.
- Advanced Speed Calibration algorithm accounts for boat heel, ensuring accurate speed readings in diverse conditions.
- 5Hz Data Updates provide real-time speed and heel/pitch information for immediate feedback.
- Integrated Pitch & Roll Sensing offers critical attitude data for performance optimization and safety.
- NMEA 2000 Backbone Cabling Pack Included simplifies installation and networking.
- Expandable System with a spare NMEA 2000 connection point for future sensor or display additions.
Specifications
| Product Specifications | |
|---|---|
| Depth Range | Up to 100m |
| Speed Range | 0.3-45 knots |
| Speed Update Rate | 5Hz |
| Heel/Pitch Update Rate | 10Hz |
| Depth Frequency | 235KHz |
| Maximum Hull Deadrise | 22 degrees |
| Simultaneous Device Connections | Up to 3 |
| Transducer Cable Length | 6m |
Who This Is For
Sailors and powerboat owners seeking a flexible, app-free marine instrumentation solution that integrates seamlessly with existing NMEA 2000 networks. Ideal for those upgrading their system or installing new instrumentation that can be viewed on any smart device.
How It Compares
| Feature | Digital Yacht iSeaSense Wireless Speed Depth Temp Pack | NMEA 2000 compatible via adapter |
|---|---|---|
| Connectivity | NMEA 2000 & Wireless WiFi | NMEA 2000, SeaTalkNG |
| Display Method | Web browser on any smart device (smartphone, tablet, iPad) | Dedicated LCD Display, Dedicated LCD Display |
| App Required | No | No, No |
| Speed Update Rate | 5Hz | 1Hz, 1Hz |
| Pitch & Roll Sensing | Yes | No, No |
| Depth Range | 100m | Up to 300m+, Up to 100m |
Common Concerns Answered
Is the iSeaSense system difficult to set up?
Initial setup requires basic NMEA 2000 networking knowledge, including connecting the backbone, T-connectors, and terminators, along with through-hull transducer installation. The wireless configuration itself is generally straightforward.
Will the wireless signal reach consistently across my boat?
Wireless range can be influenced by the vessel's structural composition and potential electromagnetic interference. Ensure optimal placement of the wireless gateway for best performance.
Does the transducer installation require modifying the hull?
Yes, the iSeaSense transducer requires hull penetration for optimal performance and accurate readings.
Frequently Asked Questions
Does the iSeaSense Wireless Speed Depth Temp Pack require a dedicated app?
No, the iSeaSense system features a no-app web interface accessible via any web browser on your connected smart devices.
What types of devices can I use to view data from the iSeaSense system?
You can view data on any smart device with a web browser, including smartphones, iPads, and tablets.
What specific data points can the iSeaSense system display?
The system displays depth (up to 100m), speed (0.3-45 knots), water temperature, and boat heel/pitch data.
Can I connect additional NMEA 2000 devices to the iSeaSense system?
Yes, the iSeaSense system includes a spare NMEA 2000 connection point, allowing for the addition of other compatible NMEA 2000 devices.
What is the data update rate for speed and heel/trim with the iSeaSense system?
Speed data is updated at 5Hz, while pitch and heel data are updated at 10Hz.
