Egis XD Single Flex 2 ACR Relay | Boat Supply Store
This Egis XD Series Single Flex 2 ACR-Relay prevents dead-start batteries by automatically sharing charging and isolating battery banks, a critical function for vessels with multiple engines or complex charging configurations. It boasts a 500A continuous current rating and a 1500A max cranking capacity, ensuring robust performance even under heavy loads. Engineered with a mechanical switching life of 1,000,000 cycles and sealed to IP67/IP6K9K standards, this unit is built for extreme marine conditions.
Key Features
- 35-75% Reduction in mounting space and weight for superior integration.
- Eliminates Dead-Start Batteries by intelligently sharing charging and isolating banks.
- Supports Multiple Engines or independent charging systems for versatile application.
- Bullet-Proof Construction, sealed to IP67/IP6K9K for extreme durability.
- Intuitive Manual Control with lock-off/lock-on state awareness.
- Plug-and-Play Compatibility with legacy competitor systems.
- 90-95% Less Off-State Current Draw compared to competitive units.
- Simple Programmability via dip switches for user-defined configurations.
Specifications
| Product Specifications | |
|---|---|
| Continuous Current | 500A |
| Max Cranking Current | 1500A |
| Mechanical Life | 1,000,000 cycles |
| Voltage Range | 8-36 VDC |
| Off-State Current Draw | 1.3mA |
| Connector Type | DTM |
| Sealing | IP67/IP6K9K |
| Manual Override | 3-position, lockable |
| Programming | Dip switches |
| Status Display | LED |
Who This Is For
Marine electrical system installers and boat builders (OEMs) seeking a compact, high-performance battery management solution will find this ideal. Boat owners aiming to optimize battery charging and isolation for multi-engine setups or complex systems will also benefit.
How It Compares
| Feature | Egis XD Single Flex 2 ACR Relay | Blue Sea Systems ML |
|---|---|---|
| Total Continuous Current Amps | 500 | 300 |
| Max Cranking Current (Amps) | 1500 | 1500 |
| Voltage Range (VDC) | 8-36 | 12-32 |
| Off-State Current Draw (mA) | 1.3 | null |
| Mechanical Switching Life | 1,000,000 cycles | null |
| IP Rating | IP67/IP6K9K | null |
| Manual Override | 3-Position, lockable | null |
| Programmability | Yes, via dip switches | No |
| Connector Type | DTM | Studs |
Common Concerns Answered
Is the initial setup of the Egis XD Series relay complicated?
While the advanced features offer significant benefits, initial setup or programming may require referring to the installation guide for novice users. However, the dip switch programmability is designed for straightforward configuration.
Is the Egis XD Series relay a cost-effective solution?
The Egis XD Series relay represents a premium solution with advanced features, resulting in a higher price point than basic battery isolators. This investment provides superior performance, efficiency, and longevity for critical marine electrical systems.
What if I have a very basic boat electrical system and don't need advanced features?
For extremely simple setups, a more rudimentary battery isolator might suffice. However, the Egis XD Series offers long-term benefits in terms of reliability, efficiency, and scalability, making it a superior choice for those who value robust marine-grade components.
Frequently Asked Questions
What is the primary function of the Egis XD Series Single Flex 2 ACR-Relay?
The primary function is to automatically manage battery banks by sharing charging current from an alternator or shore power source while isolating the batteries to prevent dead starts and optimize charging.
How does the Egis XD Series relay reduce mounting space and weight?
Its advanced internal design and integrated components allow for a 35-75% reduction in size and weight compared to traditional ACR systems, enabling easier installation in space-constrained areas.
What is the IP rating of the Egis XD Series relay?
The Egis XD Series relay is sealed to IP67 and IP6K9K standards, indicating it is protected against dust ingress and high-pressure, high-temperature washdowns, making it suitable for virtually any mounting location.
Can the Egis XD Series relay be used with multiple engines or independent charge systems?
Yes, it is specifically designed to support multiple engines or independent charge systems, providing efficient battery management across complex electrical configurations.
How is the Egis XD Series relay programmed?
The relay is programmed using simple dip switches located on the unit, allowing for easy configuration of its operational parameters without the need for specialized software.
