Garmin Solenoid Power Cable for Autopilots | Boat Supply Store
This specialized power cable is engineered to protect the Engine Control Unit (ECU) of Garmin GHP Reactor Autopilot systems operating with solenoid steering configurations. It incorporates integrated protection diodes and self-healing fuses to mitigate hazardous voltage spikes originating from hydraulic solenoid coils, thereby enhancing system longevity and operational reliability. This cable is crucial for maintaining the integrity of your autopilot's electronic components in demanding marine environments.
Key Features
- Protects ECU from hazardous voltages
- Integrates advanced protection diodes
- Features self-healing fuses
- Designed for solenoid steering configurations
- Ensures system longevity
- Enhances autopilot reliability
- Compatible with GHP Reactor corepacks
- Specifically for hydraulic solenoid coils
Specifications
| Product Specifications | |
|---|---|
| Brand | Garmin |
| SKU | CWR108309 |
| MPN | 010-11533-11 |
| Category | Marine Navigation & Instruments | Autopilots |
| Protection Features | Integrated protection diodes and self-healing fuses |
| Voltage Spike Protection | Protects ECU from voltages generated by hydraulic solenoid coils |
| Compatibility | Garmin GHP Reactor Mechanical/Solenoid/Retrofit corepack |
Who This Is For
Marine boat owners and certified technicians actively installing or performing maintenance on Garmin GHP Reactor Autopilot systems that utilize a solenoid configuration for helm control. This cable is specifically for vessels relying on hydraulic steering with an autopilot.
How It Compares
| Feature | Garmin Solenoid Power Cable for Autopilots | Raymarine |
|---|---|---|
| Integrated Protection Diodes | Yes | No |
| Self-Healing Fuses | Yes | No |
| ECU Protection for Solenoid Coils | Yes | No |
| Compatible Autopilot Corepack | Garmin GHP Reactor Mechanical/Solenoid/Retrofit | Evolution Autopilots |
Common Concerns Answered
It's hard to find replacement parts for my older autopilot. Is this readily available?
This Garmin Solenoid Power Cable is a current production item, designed as a reliable replacement for existing solenoid power cables within compatible Garmin GHP Reactor Autopilot systems, addressing sourcing challenges for essential components.
Will this cable work with my non-Garmin autopilot system components?
This power cable is specifically engineered and calibrated for seamless integration with Garmin GHP Reactor Autopilot corepacks in solenoid configurations. Compatibility with non-Garmin components is not supported.
Is the integrated protection really necessary for my specific autopilot setup?
The integrated protection diodes and self-healing fuses are designed to safeguard the autopilot ECU from damaging voltage spikes inherent in hydraulic solenoid operation, directly contributing to system longevity and preventing costly repairs, making it a critical protective measure.
Frequently Asked Questions
What is the primary purpose of the Garmin Solenoid Power Cable?
Its primary purpose is to protect the autopilot ECU from voltage spikes generated by hydraulic solenoid coils, ensuring the reliable and long-term operation of the GHP Reactor Autopilot system.
What Garmin autopilot corepacks is this cable compatible with?
This cable is compatible with the Garmin GHP Reactor Mechanical, Solenoid, and Retrofit corepacks.
Does this cable provide protection against hazardous voltages?
Yes, this cable features integrated protection diodes and self-healing fuses specifically designed to protect the ECU from hazardous voltages generated by hydraulic solenoid coils.
What are the specific protection features integrated into this cable?
The cable integrates protection diodes to suppress voltage spikes and self-healing fuses to interrupt overcurrent conditions, thereby safeguarding the autopilot ECU.
Is this cable a direct replacement for existing solenoid power cables in Garmin systems?
Yes, this cable is designed as a direct replacement for existing solenoid power cables within compatible Garmin GHP Reactor Autopilot systems, facilitating straightforward installation for maintenance or upgrades.
