Garmin TM265LH 12-Pin Transom Mount Transducer | Boat Supply Store
Designed for serious offshore navigation and fishing, this 1 kW plastic transom mount transducer delivers exceptional detail in deep water environments. Its dual-frequency operation, spanning 42-65 kHz for low-frequency penetration and 130-210 kHz for high-resolution imaging, provides comprehensive underwater visibility down to 3,000 feet. Boaters navigating the Gulf of Mexico or targeting deep-water species will benefit from its precise bottom contour and structure definition.
Key Features
- 1 kW power output for superior deep-water penetration
- Dual frequency operation (42-65 kHz & 130-210 kHz) for versatile sonar returns
- Deep water capability up to 3,000 feet
- Detailed bottom imaging for precise structure and contour identification
- Adjustable transom angle from 3 to 21 degrees for optimal installation
- Integrated depth and temperature sensors for comprehensive environmental data
- Plastic transom mount design for straightforward installation
- 12-pin connector ensures compatibility with select Garmin marine electronics
Specifications
| Product Specifications | |
|---|---|
| Power Output | 1 kW |
| Mount Type | Plastic Transom Mount |
| Frequency | Dual (42-65 kHz / 130-210 kHz) |
| Maximum Depth | 3,000 feet |
| Beamwidth (Low Frequency) | 16-25 degrees |
| Beamwidth (High Frequency) | 6-10 degrees |
| Transom Angle | 3-21 degrees |
| Sensors | Depth and Temperature |
| Connector | 12-Pin |
Who This Is For
Boaters requiring detailed underwater imagery in deep water environments, including serious anglers and commercial fishermen. This transducer is ideal for those who need to understand the underwater landscape for advanced navigation and targeting bottom structure.
How It Compares
| Feature | Garmin TM265LH 12-Pin Transom Mount Transducer | Competitor |
|---|---|---|
| Power Output | 1 kW | 1 kW |
| Mount Type | Plastic Transom Mount | Bronze Thru-hull |
| Low Frequency Range | 42-65 kHz | 42-65 kHz |
| High Frequency Range | 130-210 kHz | 150-250 kHz |
| Max Depth | 3,000 feet | — |
| Connector Type | 12-Pin | — |
Common Concerns Answered
Is the installation process difficult for the Garmin TM265LH transducer?
Installation requires careful measurement and precise mounting to ensure optimal sonar performance and prevent hull damage. While it is a transom mount and does not require hull penetration, achieving the correct angle adjustment is critical for effectiveness.
What display units are compatible with the Garmin TM265LH transducer?
This transducer requires a compatible Garmin unit that features a 12-pin transducer port for full functionality. Please verify your specific Garmin chartplotter or sonar unit has this connection.
How does the price of the TM265LH compare to other options?
While the price reflects its advanced deep-water capabilities and 1 kW power output, it is a significant investment. However, its performance in demanding marine environments often justifies the cost for serious users.
Frequently Asked Questions
What is the maximum depth capability of the Garmin TM265LH transducer?
The Garmin TM265LH transducer is rated for a maximum depth capability of 3,000 feet.
What is the operating frequency range of the Garmin TM265LH transducer?
The Garmin TM265LH operates on dual frequencies: 42-65 kHz for the low band and 130-210 kHz for the high band.
What is the beamwidth of the Garmin TM265LH transducer?
The beamwidth is 16-25 degrees for the low frequency and 6-10 degrees for the high frequency.
What type of transom angle is compatible with the Garmin TM265LH transducer?
The transducer is designed for transoms with angles between 3 and 21 degrees.
What Garmin devices are compatible with the TM265LH transducer?
The TM265LH requires a Garmin unit with a 12-pin transducer port. Specific compatibility should be verified with your Garmin chartplotter or sonar model.
