Description
Hella Marine Red LED Courtesy Light | Boat Supply Store
Maintain safe and functional navigation with this low-profile courtesy lamp designed for extreme marine conditions. Its completely sealed IP 67 rating ensures robust performance in wet environments, while the 316 stainless steel bezel offers superior corrosion resistance. Operating on a wide Multivolt 12/24V DC range with an ultra-low 0.5W power draw, it's ideal for powering up any vessel, from a flats skiff on the Texas coast to a larger yacht traversing the Gulf.
Key Features
- Surface Mount for straightforward installation
- Red LED illumination for discreet courtesy lighting
- 316 Stainless Steel Bezel for premium corrosion resistance and aesthetics
- UV and Impact Resistant Grilamid Lens for enhanced durability
- IP 67 Sealed for reliable interior or exterior wet or dry application
- Multivolt 12/24V DC compatibility for versatile power integration
- Low Power Consumption at only 0.5W to minimize battery drain
- CE Approved for assured compliance with safety standards
Specifications
| Product Specifications | |
|---|---|
| Brand | Hella Marine |
| Model | Surface Mount Oblong LED Courtesy Lamp |
| LED Color | Red |
| Bezel Material | Polished 316 Stainless Steel |
| Lens Material | Grilamid |
| Operating Voltage | Multivolt 12/24V DC |
| Power Consumption | 0.5W |
| Sealing | IP 67 |
| Application | Interior or Exterior, Wet or Dry |
| Mounting | Surface Mount |
| Cable Length | 120mm |
| Approvals | CE |
Who This Is For
Boat owners and marine professionals requiring robust, low-profile courtesy lighting for critical areas. Ideal for those prioritizing superior material durability like 316 stainless steel and a high degree of environmental sealing.
How It Compares
| Feature | Hella Marine Red LED Courtesy Light | Competitor |
|---|---|---|
| Mounting Type | Surface Mount | Surface Mount, Flush Mount |
| Bezel Material | 316 Stainless Steel | Plastic, Stainless Steel |
| Lens Material | Grilamid | Acrylic, Acrylic |
| Operating Voltage | Multivolt 12/24V DC | 12V DC, 10-30V DC |
| Degree of Protection | IP 67 | IP65, IP67 |
| Power Consumption | 0.5W | 0.6W, 2W |
Common Concerns Answered
Will the limited beam spread be an issue for my large boat?
While designed for efficient courtesy illumination, the beam spread is typical for this type of fixture. For expansive areas, consider strategic placement of multiple units or supplementing with broader flood lighting.
I need a different color temperature or brightness, can this light be modified?
This specific model is engineered with a red LED for its specified purpose. If alternative color temperatures or brightness levels are required, exploring other Hella Marine models would be necessary.
Is the pre-wired cable long enough for all installations?
The included 120mm of marine cable is standard for many surface mount applications. For custom installations requiring extended runs, plan for splicing in additional marine-grade wiring.
Frequently Asked Questions
Is this Hella Marine courtesy lamp suitable for exterior use?
Yes, the completely sealed IP 67 rating makes it suitable for interior or exterior applications in wet or dry conditions.
What is the power consumption of this Hella Marine LED lamp?
This Hella Marine LED lamp has a very low power consumption of only 0.5W.
What type of bezel does this Hella Marine courtesy lamp have?
This Hella Marine courtesy lamp features a polished 316 stainless steel bezel.
What is the degree of protection for this Hella Marine LED lamp?
This Hella Marine LED lamp has a degree of protection rated at IP 67, indicating complete dust ingress protection and protection against temporary immersion in water.
Does this Hella Marine courtesy lamp come with mounting hardware?
Yes, this Hella Marine courtesy lamp includes stainless steel screws for mounting.
