Humminbird XTM-14-HW-MDI-T Trolling Motor Transducer | Boat Supply Store
Anglers targeting precise underwater structure and fish identification will find this transducer essential for elevated down-imaging performance. It delivers unparalleled MEGA Down Imaging+ detail utilizing 800kHz for 125ft max depth and 455kHz for 400ft max depth, alongside versatile Dual Spectrum CHIRP 2D sonar capable of reaching 1200ft. The integrated temperature sensor provides critical environmental data for effective bait presentation. This transducer is engineered for seamless integration with Humminbird SOLIX™ and APEX™ series fishfinders, maximizing the clarity and resolution of your sonar returns, particularly beneficial for structure fishing in lakes like Lake Fork.
Key Features
- Unparalleled MEGA Down Imaging+ detail for precise structure identification.
- Versatile Dual Spectrum CHIRP 2D sonar for broad underwater coverage.
- Enhanced depth penetration with 400ft max for 455kHz DI+ and 1200ft for 2D CHIRP.
- Integrated temperature sensor for real-time water condition monitoring.
- Direct trolling motor mount design for optimal deployment.
- High-resolution imaging at 800kHz and 1.2 MHz frequencies.
- Robust 15-foot cable length for flexible installation.
- Designed for seamless compatibility with SOLIX™ and APEX™ units.
Specifications
| Product Specifications | |
|---|---|
| Imaging Technology | MEGA Down Imaging+, Dual Spectrum CHIRP |
| MEGA Down Imaging+ Frequencies | 800kHz, 455 kHz, 1.2 MHz |
| MEGA Down Imaging+ Max Depth (800kHz) | 125ft |
| MEGA Down Imaging+ Max Depth (455kHz) | 400ft |
| MEGA Down Imaging+ Max Depth (1.2MHz) | 200ft |
| Dual Spectrum CHIRP Frequencies | 150-220kHz |
| Dual Spectrum CHIRP Max Depth | 1200ft |
| Temperature Sensor | Yes |
| Cable Length | 15-foot |
| Compatibility | Humminbird SOLIX™ and APEX™ models |
| Physical Dimensions | 7.15" long by 2.3" wide |
Who This Is For
Anglers utilizing Humminbird SOLIX™ or APEX™ series fishfinders seeking to optimize their trolling motor's sonar capabilities. This transducer is ideal for those who demand superior down-imaging clarity and dual-spectrum sonar performance for locating fish and structure in various water depths.
How It Compares
| Feature | Humminbird XTM-14-HW-MDI-T Trolling Motor Transducer | Competitor |
|---|---|---|
| Imaging Technology | MEGA Down Imaging+, Dual Spectrum CHIRP | UHD ClearVü, UHD SideVü, CHIRP Traditional |
| MEGA Down Imaging+ Max Depth | 200ft (1075-1150 kHz) | — |
| Dual Spectrum CHIRP Max Depth | 1200ft (150-220kHz) | — |
| Temperature Sensor | Yes | Yes |
| Cable Length | 15 Feet | — |
Common Concerns Answered
Will this transducer fit my trolling motor?
The physical dimensions are 7.15" long by 2.3" wide. While designed for trolling motor mounting, some specific skeg and propeller clearances may present challenges. It is advised to measure your trolling motor's clearance before purchase.
Is this transducer compatible with all Humminbird fishfinders?
This transducer is specifically designed for and compatible with Humminbird SOLIX™ and APEX™ series models to utilize its full MEGA Down Imaging+ and Dual Spectrum CHIRP capabilities.
How does the imaging quality compare to other brands?
This transducer provides advanced MEGA Down Imaging+ for highly detailed underwater views and versatile Dual Spectrum CHIRP sonar, offering competitive resolution and depth penetration within its specified frequency ranges.
Frequently Asked Questions
What trolling motors is the Humminbird XTM-14-HW-MDI-T compatible with?
This transducer is designed to mount on trolling motors and is compatible with Humminbird SOLIX™ and APEX™ series fishfinders. Specific trolling motor shaft and propeller clearances should be verified.
What is the maximum depth for MEGA Down Imaging+ with this transducer?
MEGA Down Imaging+ offers a maximum depth of 125ft at 800kHz, 400ft at 455kHz, and 200ft at 1.2 MHz.
What is the cable length of the Humminbird XTM-14-HW-MDI-T transducer?
The Humminbird XTM-14-HW-MDI-T transducer includes a 15-foot cable.
Does this transducer include a temperature sensor?
Yes, this transducer features a built-in temperature sensor to provide real-time water temperature readings.
What frequencies does the Dual Spectrum CHIRP sonar operate on?
The Dual Spectrum CHIRP sonar operates on frequencies between 150-220kHz.
