Description
Icom IC-M330 VHF Radio w/ GPS - White | Boat Supply Store
Ensure clear maritime communication and enhance your vessel's safety profile with this compact, fixed-mount VHF radio. Its integrated GPS receiver provides accurate position data for distress calls, meeting ITU-R M493-13 DSC class D standards with a front-mounted water-resistant speaker delivering a powerful 80 dB output. Ideal for offshore fishing excursions or navigating the waters around Galveston Bay, this unit offers reliable performance in a small footprint.
Key Features
- Integrated GPS for accurate distress calls and navigation.
- Compact Design saves valuable helm space.
- Water-Resistant Front Speaker ensures clear audio output.
- DSC (Digital Selective Calling) for enhanced distress signaling.
- Intuitive User Interface simplifies operation.
- NMEA 2000 Connectivity for data integration.
- IPX7 Waterproof Rating provides protection against submersion.
- Powerful 25W Transmission for extended range communication.
Specifications
| Product Specifications | |
|---|---|
| Dimensions (W x H x D) | 6.1" x 3.0" x 4.4" (156.5 x 76 x 112 mm) |
| Weight | Approx. 1.2 lb (550 g) |
| Power Supply | 12V DC |
| Power Output | 25W (High) / 1W (Low) |
| Current Drain (approx. at 13.8V DC) | Transmit @ 25W: 5.0A, Receive (Max Audio): 1.5A |
| Water Resistance | IPX7 (Front Panel) |
| Operating Temperature | -4°F to +131°F (-20°C to +55°C) |
| GPS Receiver | Internal |
| DSC Class | Class D |
| Speaker Output | 80 dB (at 1m) |
Who This Is For
Boaters requiring reliable onboard communication and essential safety features in a space-saving form factor. This radio is perfect for small to medium-sized vessels and those navigating coastal or inland waterways where clear hailing and distress signaling are paramount.
How It Compares
| Feature | Icom IC-M330 VHF Radio w/ GPS - White | Front |
|---|---|---|
| Dimensions (W x H x D) | 6.1" x 3.0" x 4.4" | 6.5" x 3.0" x 5.5" |
| GPS | Integrated | External Required |
| DSC Class | D | D |
| Water Resistance | IPX7 (Front) | IPX7 |
| NMEA 2000 | Yes | Yes |
Common Concerns Answered
Is the GPS accuracy reliable for emergency use?
Yes, the integrated GPS receiver provides precise position data essential for DSC distress calls, meeting stringent maritime safety standards.
How is the audio quality of the speaker?
The front-mounted, water-resistant speaker is engineered for clarity, delivering a strong 80 dB output to ensure your transmissions are heard even in noisy marine environments.
Is this radio difficult to install on a boat?
With an installation difficulty rating of 1, this compact VHF radio is designed for straightforward mounting, making it accessible for DIY installation.
Frequently Asked Questions
What is DSC and why is it important?
DSC (Digital Selective Calling) is a maritime standard for sending distress alerts and other digital messages. It allows for quick and accurate communication of your vessel's position and identification in emergencies.
Does the Icom IC-M330 have built-in GPS?
Yes, the IC-M330 features an internal GPS receiver, eliminating the need for an external GPS antenna for its position reporting functions.
What is the meaning of IPX7 rating?
An IPX7 rating signifies that the front panel of the radio is protected against immersion in water up to 1 meter for 30 minutes, making it suitable for washdown and spray exposure.
Can this radio be connected to a boat's network?
Yes, the IC-M330 is equipped with NMEA 2000 connectivity, allowing it to integrate with compatible onboard data networks for shared information.
What is the maximum transmission power?
The Icom IC-M330 has a maximum transmission power of 25 Watts, with a lower power setting of 1 Watt for shorter-range communication.
