Mastervolt Battery Mate 1603 IG Isolator | Boat Supply Store
For vessels requiring efficient and simultaneous charging of multiple battery banks from a single source, the Mastervolt Battery Mate 1603 IG delivers advanced performance. This 120 Amp, 3-bank electronic isolator employs MOSFET technology to achieve negligible voltage loss, ensuring batteries receive optimal charge current. It is fully compatible with all alternators and chargers, and includes an IG contact for specific alternator types, making it ideal for complex marine electrical configurations like those found on offshore sportfishing boats.
Key Features
- Charge multiple batteries simultaneously from one source
- Compatibility with any alternator or battery charger
- Negligible voltage loss ensures efficient battery charging
- Advanced electronic MOSFET technology
- Compensates for voltage variations in charging systems
- DIN rail mountable for straightforward installation
- IG contact for specialized alternators needing excitation
- Robust 120 Amp rating for high-demand systems
Specifications
| Product Specifications | |
|---|---|
| Amperage Rating | 120 Amp |
| Bank Configuration | 3 Bank |
| Technology | Electronic MOSFET |
| Voltage Loss | Negligible |
| Compatibility | All alternators and battery chargers |
| Mounting | DIN rail mountable |
| Special Features | IG contact for alternators requiring external excitation/voltage sensing |
Who This Is For
Boat owners and RV enthusiasts who need to efficiently charge multiple independent battery banks from a single charging source, such as an engine alternator or shore power charger, without compromising charge voltage or speed. This unit is designed for users demanding maximum charging efficiency across a complex battery system.
How It Compares
| Feature | Mastervolt Battery Mate 1603 IG Isolator | Competitor |
|---|---|---|
| Technology | Electronic MOSFET | Automatic Charging Relay (ACR), Intelligent Battery Combiner |
| Voltage Loss | Negligible | Very Low, Low |
| Number of Banks | 3 | 2 (typical), 2 |
| Amperage Rating | 120A | 120A, 120A |
| IG Contact | Yes | No, No |
Common Concerns Answered
Is the installation of the Mastervolt Battery Mate 1603 IG complex?
While designed for DIN rail mounting, understanding the wiring for the input, output banks, and the IG contact requires basic electrical knowledge. We recommend professional installation for those unfamiliar with marine electrical systems to ensure optimal performance and safety.
Why is the Mastervolt Battery Mate 1603 IG more expensive than basic diode isolators?
The advanced electronic MOSFET technology offers superior performance with negligible voltage loss, ensuring faster and more complete battery charging compared to older diode-based systems or simpler ACRs. This technological advantage directly contributes to better battery health and charging efficiency.
I'm concerned about setup complexity, especially the IG contact.
The IG contact is for specific alternator types that require external excitation or voltage sensing. Detailed diagrams and explanations are available in the manual. If your alternator type is unclear, consulting an marine electrical professional is advisable for seamless integration.
Frequently Asked Questions
What is a battery isolator?
A battery isolator is an electrical device that allows a single charging source, such as an alternator or a battery charger, to charge multiple batteries simultaneously without allowing the batteries to discharge into each other. It ensures each battery bank receives its appropriate charge.
How does the Mastervolt Battery Mate 1603 IG work?
It uses advanced MOSFET electronic switching to intelligently direct charging current from a single source to up to three separate battery banks. Unlike diode isolators, it does so with minimal voltage drop, maximizing charge efficiency and speed.
Can I use the Battery Mate with any type of alternator or battery charger?
Yes, the Mastervolt Battery Mate 1603 IG is designed for compatibility with all alternator and battery charger types. It also features an IG contact for specific alternator models that require external voltage sensing or excitation.
What is the voltage loss with the Battery Mate?
The Mastervolt Battery Mate 1603 IG utilizes electronic MOSFET technology which results in negligible voltage loss, significantly less than traditional diode isolators. This ensures your batteries receive a fuller charge from the available charging voltage.
How is the Battery Mate installed?
The unit is designed for easy DIN rail installation, allowing for secure and organized mounting within your vessel's electrical panel. Proper wiring to the input, output battery banks, and optional IG contact is crucial and requires basic electrical understanding.
