Pacer Heat Shrink Ring Terminals #10 Stud | Boat Supply Store
Ensure robust electrical connections essential for maintaining power integrity on saltwater vessels. These Pacer terminals, constructed from corrosion-resistant tinned copper, are rated for 600 volts and operate reliably within a temperature range of -55°C to 125°C. They are specifically designed for terminating 22-18 AWG conductors onto a #10 stud, offering a critical safeguard against vibration and environmental ingress common during offshore fishing excursions.
Key Features
- Corrosion resistant tinned copper construction for marine environments
- Integrated heat shrink tubing for superior insulation and strain relief
- Optimized for 22-18 AWG wire gauges for precise fitment
- #10 stud size compatibility for standard marine hardware
- 600 Volt rating ensuring safe operation under demanding loads
- Wide operating temperature range of -55°C to 125°C for all climates
- Color-coded red for immediate gauge identification
- 100-pack for efficient project completion
Specifications
| Product Specifications | |
|---|---|
| Wire Gauge | 22-18 AWG |
| Stud Size | #10 |
| Quantity | 100 Pack |
| Material | Tinned Copper |
| Voltage Rating | 600 Volts |
| Operating Temperature | -55°C to 125°C |
| Terminal Pad Width | 0.32 inches |
| Color | Red |
Who This Is For
Ideal for marine electricians undertaking complex system installations and DIY boat owners performing essential electrical maintenance. Anyone requiring a reliable, insulated termination for 22-18 AWG wires onto a #10 stud will find these terminals invaluable for marine applications.
How It Compares
| Feature | Pacer Heat Shrink Ring Terminals #10 Stud | Ancor Heat Shrink Ring Terminal |
|---|---|---|
| Wire Gauge | 22-18 AWG | 22-18 AWG |
| Stud Size | #10 | #10 |
| Color | Red | Red |
| Quantity | 100 Pack | 100 Pack |
| Material | Tinned Copper | Tinned Copper |
| Insulation Type | Heat Shrink | Heat Shrink |
| Voltage Rating | 600 Volts | 600 Volts |
| Operating Temperature | -55°C to 125°C | -55°C to 125°C |
| Terminal Pad Width | 0.32" | 0.32" |
Common Concerns Answered
How do I ensure a secure crimp on smaller gauge wires?
Use a high-quality, properly sized crimping tool designed for 22-18 AWG wire to achieve a solid mechanical bond within the terminal barrel. Ensure the wire conductor is fully inserted and the crimp is applied firmly.
What if the heat shrink tubing doesn't seal completely?
Ensure the heat gun or torch is applied evenly and at the correct distance, maintaining consistent heat across the entire tubing surface until it fully conforms and seals. Preheating the terminal slightly can sometimes aid in uniform shrinking.
Will the heat shrink hold up in harsh marine conditions?
These terminals feature heat shrink tubing specifically designed for marine environments, offering excellent insulation and protection against moisture, salt spray, and abrasion when properly installed with sufficient heat.
Frequently Asked Questions
What is the maximum wire gauge this heat shrink ring terminal can accommodate?
This heat shrink ring terminal is designed for wire gauges ranging from 22 AWG to 18 AWG.
What is the stud size for this ring terminal?
The stud size accommodated by this ring terminal is #10.
What is the operating temperature range for this terminal?
The operating temperature range for this terminal is from -55°C to 125°C.
What material is the terminal made of?
The terminal is constructed from tinned copper for superior corrosion resistance in marine applications.
How many terminals are included in this pack?
This pack includes 100 heat shrink ring terminals.
