Pacer Deutsch DT 12-Pos Receptacle & Wedge Lock Kit | Boat Supply Store
Establish robust, waterproof electrical connections in demanding marine environments with Pacer's Deutsch DT Receptacle & Wedge Lock Kits. Engineered for reliability, these kits provide a field-proven solution for wire-to-wire applications within the 20-14 AWG range. Featuring IP67 sealing and operational temperatures from -55°C to 125°C, they ensure secure connections even under extreme conditions, such as those encountered during offshore fishing or coastal cruising.
Key Features
- Environmentally Sealed for maximum protection against ingress
- Waterproof, Vibration, and Shock Resistant design for marine applications
- Accommodates 20-14 AWG Wire Sizes for versatile installation
- Designed for Size 16 Contacts with a 13 Amp rating
- Easy Installation, Connection, and Disconnection process
- Includes Housing and Wedge Lock for convenient procurement
- Redundant Silicone Seals ensure superior environmental protection
- Hand-Insertable and Removable Contacts simplify assembly
Specifications
| Product Specifications | |
|---|---|
| Number of Positions | 12 |
| Wire Gauge | 20-14 AWG |
| Contact Size | 16 |
| Contact Amp Rating | 13 Amp |
| IP Rating | IP67 |
| Operating Temperature | -55°C to 125°C |
| Recognition | UL-94 Recognized |
| Package Quantity | 5 Pack |
Who This Is For
Ideal for marine technicians, boat builders, and DIY enthusiasts requiring durable, environmentally sealed electrical connections on vessels. This kit is specifically beneficial for creating reliable wire-to-wire circuits for essential boat systems.
How It Compares
| Feature | Pacer Deutsch DT 12-Pos Receptacle & Wedge Lock Kit | Competitor |
|---|---|---|
| Number of Cavities | 12 | 12 |
| Contact Size | 16 | 16 |
| Wire Size | 20-14 AWG | 20-14 AWG |
| IP Rating | IP67 | IP67 |
| Package Size | 5 Pack | Typically less capable |
Common Concerns Answered
Are pins and sockets included with this kit?
No, this kit includes the Deutsch DT receptacle housings and wedge locks only. Pins and sockets are sold separately and must be sourced to complete the connector assembly.
Is it difficult to source the correct contacts for these connectors?
While contacts are sold separately, Deutsch size 16 contacts are a standard in the industry for this series, readily available for 20-14 AWG wire sizes from various marine electrical suppliers.
How reliable are these connectors in harsh marine conditions?
Pacer's Deutsch DT connectors are specifically designed for the marine environment, offering IP67 rated, waterproof, vibration, and shock resistance. Their robust construction ensures dependable electrical connections on vessels facing rough seas or constant moisture.
Frequently Asked Questions
What is the wire gauge range for Pacer Deutsch DT Receptacle & Wedge Lock Kits?
These kits are designed for wire sizes ranging from 20 AWG to 14 AWG.
Are pins and sockets included with the Pacer Deutsch DT Receptacle & Wedge Lock Kit?
No, this kit contains only the 12-position receptacle housings and wedge locks. Pins and sockets must be purchased separately.
What is the IP rating of Pacer Deutsch DT Connectors?
Pacer Deutsch DT Connectors, including this receptacle kit, are rated IP67, ensuring protection against dust and immersion in water up to 1 meter for 30 minutes.
What is the operating temperature range for these connectors?
These connectors are built to operate reliably within a wide temperature range of -55°C to 125°C.
What does the 'DT Series' designation mean for Deutsch connectors?
The 'DT Series' designation indicates a robust, environmentally sealed connector family from Deutsch, specifically engineered for reliability in harsh environments such as the marine industry, suitable for wire-to-wire and wire-to-device applications.
