Description
Raymarine RSW Wired Wind Transducer | Boat Supply Store
Serious sailors and offshore racers demanding precise True Wind data for tactical advantage will find the Raymarine RSW Wired Smart Wind Transducer invaluable. This unit bypasses complex calibration and additional processors, directly outputting highly accurate wind speed and direction via its 'Install & Go' Smart Wind technology. Operating on 12V DC and featuring a robust design with a waterproof rating of IPx6/IPx7 for the transducer, it's built to withstand marine environments and measures wind speeds up to 115 mph.
Key Features
- Professional-level wind sensor for highly accurate calibrated wind speed and direction data
- Supplied with a 30-meter Smart Wind mast cable
- Install & Go technology eliminates need for additional processors or extensive calibration
- Finely tuned and balanced through rigorous wind tunnel testing
- Delivers trusted, high-accuracy True Wind data for smarter sailing
- Directly provides reliable True Wind data
- Rugged construction with IPx6/IPx7 waterproof rating
- Simplified integration with Raymarine Alpha Performance Displays and Axiom Chartplotters
Specifications
| Product Specifications | |
|---|---|
| Brand | Raymarine |
| Model | RSW Wired Smart Performance Wind Transducer |
| SKU | CWR102244 |
| MPN | E70670 |
| Arm Length | Short |
| Cable Length | 30m |
| Power Requirement | 12V DC (9-16V DC range) |
| Connectivity | SeaTalk NG |
| NMEA 2000 LEN | 1 |
| Fuse Rating | 5A |
| Operating Temperature Range | -25°C to +55°C |
| Transducer Waterproof Rating | IPx6/IPx7 |
| Gateway Waterproof Rating | IPx3 |
| Max Wind Speed Measurement | 115 mph (185 kph) |
| Transducer Length | 540.712 mm (excluding cable) |
| Transducer Width | 46.96 mm |
| Safety Certifications | EN 60945:2002 (exposed) |
Who This Is For
Serious sailors and offshore racers who require precise and reliable wind data for optimal performance and decision-making. Ideal for those integrating with Raymarine's Alpha Performance Displays and Axiom Chartplotters.
How It Compares
| Feature | Raymarine RSW Wired Wind Transducer | NMEA 2000 |
|---|---|---|
| Connectivity | Wired (SeaTalk NG) | Wireless, Wired |
| Power Source | 12V DC (via SeaTalk NG) | Solar, 12V DC |
| Mast Cable Length | 30m | N/A (Wireless), 30m |
| Max Wind Speed Measurement | 115 mph (185 kph) | 100 knots (115 mph), 50 knots |
| Calibration | Install & Go (minimal calibration) | App-based calibration, Requires calibration via display unit |
Common Concerns Answered
What are common complaints about wind direction accuracy?
Occasional reports of wind direction inaccuracies can occur in very light or turbulent air, which is a common characteristic across many wind sensors in these challenging conditions.
Is the 30m cable length sufficient for all masts?
While 30m is a substantial cable length, some users with exceptionally tall masts might prefer a longer standard option. However, this length is adequate for the majority of installations.
How does the 'Install & Go' technology address calibration concerns?
The 'Install & Go' Smart Wind technology is specifically designed to eliminate complex calibration procedures and the need for expensive additional processors, significantly simplifying setup for reliable True Wind data.
Frequently Asked Questions
What is the accuracy of the Raymarine RSW Wired Smart Wind Transducer?
The transducer offers professional-level accuracy for calibrated wind speed and direction data, providing trusted, high-accuracy True Wind data for enhanced sailing performance.
What is included in the Raymarine RSW Wired Smart Wind Transducer package?
The package includes the wired wind transducer with a short arm design and a 30-meter Smart Wind mast cable.
How is the Raymarine RSW Wired Smart Wind Transducer calibrated?
It features 'Install & Go' technology, which significantly reduces the need for extensive calibration. It is finely tuned and balanced through rigorous wind tunnel testing.
What is the power requirement for the Raymarine RSW Wired Smart Wind Transducer?
The transducer operates on 12V DC, with an acceptable input range of 9-16V DC, and connects via the SeaTalk NG network.
What is the maximum wind speed the Raymarine RSW Wired Smart Wind Transducer can measure?
The transducer is capable of accurately measuring wind speeds up to 115 mph (185 kph).
