Samlex 1000W Modified Sine Wave Inverter | Boat Supply Store
This Samlex 1000W Modified Sine Wave Inverter provides essential 115V AC power from a 12V DC source, crucial for operating standard electronics on vessels or in mobile environments. Delivering 1000 watts continuous output and 2000 watts surge capacity, it efficiently handles moderate power demands for applications where pure sine wave is not a strict requirement. Its compact dimensions of 7.1 x 9.84 x 2.32 inches ensure easy integration into tight spaces, common on fishing boats navigating the Gulf Coast. The unit features critical safety protections including thermal, battery, overload, and short circuit fault shutdowns, making it a dependable choice for powering essential AC devices.
Key Features
- 1000 Watts continuous power output
- 2000 Watts surge power capacity
- Modified Sine Wave output for broad compatibility
- 12V DC input for common battery systems
- 115V AC output at 60 Hz
- ETL safety listed for assured performance
- Compact design for efficient space utilization
- Universal protection circuits guard against faults
Specifications
| Product Specifications | |
|---|---|
| Input Voltage | 12V DC |
| Output Voltage | 115V AC |
| Frequency | 60 Hz |
| Continuous Power Output | 1000 Watts |
| Surge Power Capacity | 2000 Watts |
| Cooling | Load controlled fan |
| Low Battery Alarm | Yes |
| Protection Circuits | Thermal, battery, overload, short circuit, earth fault |
| Soft Start Technology | Yes |
| Cool Surface Technology | Yes |
| Low Interference Technology | Yes |
| Safety Listing | ETL |
| Warranty | 2 Year Limited |
| Weight | 3.69 lbs (1.72 kg) |
| Dimensions | 7.1 x 9.84 x 2.32 inches (180 x 250 x 59 mm) |
| Outlets | 2 |
| Optional Remote Control | SAM-RC |
Who This Is For
This inverter is ideal for boaters and RV owners seeking to power standard AC appliances and electronics from a 12V DC source. It is particularly suited for applications where sensitive electronics are not the primary load and cost-effectiveness is a consideration.
How It Compares
| Feature | Samlex 1000W Modified Sine Wave Inverter | Renogy |
|---|---|---|
| Output Type | Modified Sine Wave | Pure Sine Wave |
| Continuous Power | 1000 Watts | 1000W |
| Surge Power | 2000 Watts | 2000W |
| Input Voltage | 12V DC | 12V DC |
| Output Voltage | 115V AC | 110V AC |
| Safety Certification | ETL | ETL |
| Dimensions (in) | 7.1 x 9.84 x 2.32 | 10.2 x 8.7 x 3.5 |
| Weight (lbs) | 3.69 | 5.7 |
Common Concerns Answered
Can I run sensitive electronics like laptops or medical equipment with this Samlex 1000W inverter?
Modified sine wave inverters, including this Samlex model, may not be suitable for all sensitive electronics such as some medical devices, variable speed motors, or laser printers due to the nature of the waveform. For highly sensitive equipment, a pure sine wave inverter is recommended.
What appliances can I power with a 1000W inverter?
A 1000W inverter can power devices such as small kitchen appliances (coffee makers, blenders), power tools (drills, saws), charging stations for electronics, and lighting systems. Always check the wattage requirements of your intended appliances to ensure compatibility.
Are there any common issues with modified sine wave inverters?
The primary concern with modified sine wave output is its incompatibility with certain sensitive electronics, which can lead to malfunction or damage. Additionally, audible fan noise may be present when the unit is under load, and proper DC wiring practices are essential for safe operation.
Frequently Asked Questions
What is the difference between modified sine wave and pure sine wave inverters?
Pure sine wave inverters produce a smooth, clean AC waveform identical to utility power, suitable for all electronics. Modified sine wave inverters produce a stepped approximation of a sine wave, which is more affordable but may cause issues with sensitive electronics like motors, chargers, and audio equipment.
How do I connect this inverter to my 12V battery system?
Connect the inverter's DC input terminals directly to your 12V battery bank using appropriate gauge wiring and a properly rated DC fuse or circuit breaker. Ensure correct polarity and secure connections to prevent damage or fire hazards. Refer to the manual for specific wire gauge recommendations based on cable length.
What is the surge capacity of this inverter and what does it mean?
The surge capacity of 2000 watts means the inverter can handle a temporary, higher power draw for a short duration, which is critical for starting motors in appliances like refrigerators or pumps. This surge capability is essential for devices that require more power to initiate operation than they do to run continuously.
Does this inverter have overload protection?
Yes, the Samlex 1000W Modified Sine Wave Inverter is equipped with universal protection circuits, which include overload protection. This feature automatically shuts down the inverter if the connected load exceeds its capacity, safeguarding both the inverter and your connected devices.
What is the warranty on the Samlex 1000W Modified Sine Wave Inverter?
The Samlex 1000W Modified Sine Wave Inverter comes with a 2-year limited warranty, providing assurance of its quality and reliability for your mobile power needs.
