Scanstrut ATMOS Air Station | Boat Supply Store
Maximize your time on the water with the Scanstrut ATMOS 12V Integrated Air Station, engineered for robust marine environments. This unit features a sophisticated two-stage pump, delivering high-volume low-pressure (HVLP) inflation for rapid initial fill and then transitioning to high-pressure low-volume (HPLV) for precise inflation up to 20 PSI. Its IPX6 waterproof rating ensures reliable operation in harsh conditions, making it indispensable for quickly inflating everything from paddleboards to large towables.
Key Features
- Integrated 12V air station for seamless onboard inflation
- Efficient two-stage pump system (HVLP and HPLV) for rapid and precise inflation
- Durable brushless motor technology specifically for the marine environment
- Waterproof IPX6 rating ensures protection against water ingress
- User-friendly Soft Touch TPE buttons and bright LCD display with live voltage readout
- Safe ignition protection (ISO 8846 and SAE J1171) for gasoline-powered vessels
- Compact and shallow design allows for versatile installation options
- Convenient automatic shut-off at your pre-set target pressure
Specifications
| Product Specifications | |
|---|---|
| 12V integrated air station | Yes |
| Two-stage pump system | 0-1 PSI HVLP, 1.1-20 PSI HPLV |
| Max pressure | 20 PSI / 1.4 BAR |
| IPX6 waterproof rating | Yes (front and rear, door closed) |
| Brushless motor | Yes |
| Ignition protection | Yes (ISO 8846 and SAE J1171) |
| Power cable length | 500mm (20") |
| Power cable gauge | 14 AWG |
| Max run time | 25-minute |
| Max current draw | 12A |
| Ambient operating temperature | -20 to +50 C |
| Included accessories | Sun cover, 2.5M hose, and 6 adapters |
Who This Is For
Boat owners and watersports enthusiasts who frequently inflate paddleboards, towables, kayaks, and other inflatable watercraft. Desires a convenient, integrated, and durable onboard solution that minimizes setup time and maximizes time on the water.
How It Compares
| Feature | Scanstrut ATMOS Air Station | Airhead A4 |
|---|---|---|
| Max Pressure Output | 20 PSI / 1.4 BAR | 1.5 PSI |
| Pump Type | Two-Stage (HVLP & HPLV) | High Volume Single Stage |
| Waterproof Rating | IPX6 (front and rear, door closed) | Not specified |
| Integrated Display | Yes (LCD with Live Voltage) | No |
| Auto Shut-off | Yes (at target pressure) | No |
| Ignition Protection | Yes (ISO 8846 & SAE J1171) | No |
Common Concerns Answered
Is the Scanstrut ATMOS worth the higher price point compared to portable pumps?
The ATMOS is designed for permanent onboard installation, offering superior durability, waterproofing (IPX6), and automated features like pressure shut-off and live voltage display, which portable units lack. This integrated system minimizes setup time and ensures reliable performance in demanding marine conditions, justifying the investment for serious boaters who prioritize convenience and longevity.
Can this air station be used on any type of boat?
The ATMOS operates on a standard 12V DC system, making it compatible with most boats. Its ignition protection, certified to ISO 8846 and SAE J1171 standards, ensures safe operation on gasoline-powered vessels, a critical safety feature for many boat types.
What are the main drawbacks of the Scanstrut ATMOS?
The primary considerations are its higher initial cost compared to basic portable pumps and its limitation to 12V systems. However, these are offset by its advanced features, integrated design, and marine-specific construction.
Frequently Asked Questions
What is the maximum pressure the Scanstrut ATMOS can inflate to?
The Scanstrut ATMOS can inflate to a maximum pressure of 20 PSI (1.4 BAR).
How long can the ATMOS run continuously?
The ATMOS has a maximum continuous run time of 25 minutes.
What types of inflatable items can the ATMOS inflate?
The ATMOS is designed for efficiently inflating a wide range of inflatable items including paddleboards, towables, kayaks, dinghies, and other watercraft requiring precise pressure up to 20 PSI.
What are the installation requirements for the ATMOS?
The ATMOS requires a panel-mount installation with a minimum cavity depth of 110mm (4.33"). It needs a basic electrical connection to a 12V system and uses a foam gasket for a waterproof seal.
What is the power consumption of the ATMOS?
The ATMOS has a maximum current draw of 12A.
