Sea-Dog Voltmeter USB-C PD & USB 3.0 Charger | Boat Supply Store
Maintain optimal battery system health while simultaneously powering essential electronics with this integrated marine power socket. It features a visually intuitive rainbow voltmeter that clearly indicates voltage status across an 8-32VDC input range. For device charging, it delivers robust power via USB-C Power Delivery up to 60W at 24V and USB 3.0 Quick Charge up to 36W at 12V, with a combined output of 6A.
Key Features
- Simultaneous dual-device fast charging via USB-C PD and USB 3.0 QC.
- Visual color-coded voltage status indicator for immediate system assessment.
- Powerful USB-C charging up to 60W @ 24V input.
- Rapid USB 3.0 charging up to 36W @ 12V input.
- Versatile 8-32VDC input range suitable for most marine electrical systems.
- Durable IP65 rated and RoHS compliant construction for marine environments.
- Battery conservation with integrated On/Off button.
- Secure installation with a protective dust cap included.
Specifications
| Product Specifications | |
|---|---|
| Input | 8-32VDC |
| Output DC | 5V/6A total |
| USB-C Watts | 60W@24V |
| USB Watts | 36W@12V |
| Plug-In Side Diameter | 1-7/16" |
| Length | 1-1/2" |
| Requires Hole Size | 1-1/8" |
| RoHS Compliant | Yes |
| IP Rated | IP65 |
Who This Is For
Boaters and RV owners requiring a reliable, multi-functional power socket that integrates voltage monitoring with advanced fast-charging capabilities for their mobile electrical systems. Ideal for those who need to power and monitor devices in demanding outdoor environments.
How It Compares
| Feature | Sea-Dog Voltmeter USB-C PD & USB 3.0 Charger | Competitor |
|---|---|---|
| USB-C Charging Standard | USB-C Power Delivery (PD) | Standard USB 2.4A, Standard USB 2.1A |
| USB-A Charging Standard | USB 3.0 Quick Charge (QC) | Standard USB 2.4A, Standard USB 2.1A |
| Total USB Amperage Output | 6A (split 3A per port) | 4.8A (2.4A per port), 4.2A |
| Voltmeter Display Type | Rainbow Dial | Digital LED, Digital LED |
| Voltmeter Voltage Range | Up to 14.6 volts | 3-20V DC, 5-15V DC |
| Input Voltage Range | 8-32VDC | 12-24V DC, 12-24V DC |
| On/Off Button | Yes | No, No |
| Dust Cap | Yes | No, No |
| IP Rating | IP65 | Not Specified, Not Specified |
Common Concerns Answered
How precise is the voltage reading with the rainbow voltmeter?
The rainbow dial offers a visual, color-coded indication of voltage status, with red/orange signifying low voltage and green indicating normal operation. While less precise than a digital readout, it provides an immediate, at-a-glance assessment of system health.
Can I charge multiple high-power devices simultaneously at their maximum rates?
This unit provides a total output of 6A, which is split between the USB-C and USB-A ports. While it supports fast charging standards like USB-C PD and USB 3.0 QC, the total amperage split may be a consideration for users needing to charge several extremely high-draw devices concurrently at their absolute peak rates.
Is the rainbow voltmeter display difficult to interpret?
The color coding is designed for intuitive understanding: red/orange indicates potentially low voltage requiring attention, while green signifies normal operating voltage. This system provides a quick visual cue for boater to assess battery status without needing to read precise numbers.
Frequently Asked Questions
What is the total amperage output of the Sea-Dog Round Rainbow Voltmeter with USB & USB-C Power Socket?
The total amperage output is 6A, which is split between the USB-C and USB-A ports as needed, typically 3A per port.
What is the voltage range that the rainbow display indicates?
The rainbow dial provides a visual indication of voltage status up to 14.6 volts, with color cues for normal and low voltage ranges.
Does the USB-C port support Power Delivery (PD)?
Yes, the USB-C port supports Power Delivery (PD) and can deliver up to 60W when the input voltage is 24V.
Does the USB 3.0 port support Quick Charging (QC)?
Yes, the USB 3.0 port supports Quick Charge (QC) and can deliver up to 36W when the input voltage is 12V.
What is the required hole size for installation?
This unit requires a 1-1/8" hole for proper installation.
