Shadow-Caster 6-Channel Digital Switch Module | Boat Supply Store
Streamline your vessel's lighting system by centralizing control of up to six independent single-color light circuits. This module seamlessly integrates third-party LED fixtures into the Shadow-NET™ ecosystem, offering robust digital command via a compatible MFD or mobile application. It operates on 12/24V systems and provides 10A per channel with built-in digital overcurrent fault protection, safeguarding your electrical integrity offshore. Manual switch inputs are also available for direct operational override on complex fishing trips around the Gulf Coast.
Key Features
- Integrates up to six independent digital switches for unparalleled lighting management.
- Controls third-party lighting through the intuitive Shadow-Caster MFD and mobile app interface.
- Protects your electrical system with digital overcurrent fault protection on every channel.
- Allows manual switch override capability for direct, on-demand lighting adjustments.
- Ensures robust connectivity with IP67 rated Deutsch connections, vital for marine environments.
- Operates efficiently on standard 12/24V marine electrical systems.
- Delivers a substantial 10A capacity per channel to power diverse lighting arrays.
- Provides clear operational feedback with status LEDs for each channel and a blue backlight for power state.
Specifications
| Product Specifications | |
|---|---|
| Channels | 6-channel digital switch module |
| Lighting Type | Single-color and 3rd party lighting |
| Voltage Operation | 12/24V |
| Amperage per Channel | 10A |
| Fault Protection | Digital over current |
| Manual Input | Manual switch input |
| Connection Type | IP67 Deutsch connections |
| Backlight | Blue for power state |
| Status LEDs | Green/red status LEDs per channel |
Who This Is For
Boat owners and marine professionals seeking to consolidate and digitally manage multiple single-color lighting systems, including diverse third-party brands. This module is ideal for those requiring a centralized interface for enhanced convenience and system reliability.
How It Compares
| Feature | Shadow-Caster 6-Channel Digital Switch Module | Circuit breakers |
|---|---|---|
| Number of Channels | 6 | Up to 12 |
| Amperage per Channel | 10A | Varies by breaker |
| Digital Control | Yes (Shadow-NET™ MFD/App) | No |
| Third-Party Lighting Compatibility | Yes | Yes |
| Digital Fault Protection | Yes (Over current) | Yes |
| Manual Override | Yes | Yes |
| IP Rating (Connections) | IP67 (Deutsch) | Varies by specific panel and component |
Common Concerns Answered
Can I use the Shadow-Caster 6-Channel Digital Switch Module with lights from other brands?
Yes, this module is specifically designed to control single-color lighting from third-party brands seamlessly within the Shadow-NET™ ecosystem.
What is the maximum amperage per channel for this switch module?
Each of the six channels on this module is rated for a maximum capacity of 10A.
Does this module offer protection against overcurrent situations?
Absolutely. The module incorporates digital overcurrent fault protection for each channel, safeguarding your vessel's electrical system.
Frequently Asked Questions
What is the maximum amperage per channel for this switch module?
The maximum amperage rating per channel for the Shadow-Caster 6-Channel Digital Switch Module is 10A.
Does this module offer protection against overcurrent situations?
Yes, this module features digital overcurrent fault protection on each of its six channels to prevent damage to connected lights and wiring.
Can I manually override the digital control of the lights?
Yes, the module includes a manual switch input that allows for direct operational override of the digitally controlled lights.
What is the IP rating of the Deutsch connections on this module?
The Deutsch connections on this module are rated IP67, providing robust protection against dust and water ingress in marine environments.
Can I use this module to control RGB or multi-color lighting systems?
No, this specific module is designed for single-color lighting only and is not suitable for controlling RGB or multi-color systems without additional controllers.
