Description
Shakespeare 4186BP/L206B Nylon Ratchet Mount | Boat Supply Store
Achieve precise antenna aiming on your vessel with a robust, four-way adjustable ratchet mechanism constructed from solid nylon. This mount accommodates standard 1-14 threaded antennas, offering flexible deck or side mounting configurations. It is rated for antennas up to 8 feet in length when used in a self-supporting mode, preventing warranty voidance.
Key Features
- Adjustability: Four-way ratchet design with handle for precise aiming.
- Versatility: Suitable for deck or side mounting applications.
- Durability: Constructed from solid nylon for long-lasting marine use.
- Standard Fit: Features a standard 1-14 thread for broad compatibility.
- Secure Mounting: Bolt holes measure 5/16 inch diameter.
- Spacing: Bolt hole spacing is 3 x 1-1/2 inches on center.
- Length Limitation: Designed for antennas up to 8 feet for optimal performance.
- Reliability: Shakespeare brand quality and engineering.
Specifications
| Product Specifications | |
|---|---|
| Mounting Mechanism | Four-way ratchet with handle |
| Material | Solid Nylon |
| Thread Size | 1-14 |
| Mounting Surface | Deck or Side |
| Max Antenna Length (Self-Supporting) | 8' |
| Bolt Hole Diameter | 5/16" |
| Bolt Hole Spacing (On Center) | 3 x 1-1/2" |
Who This Is For
Boaters and marine enthusiasts requiring a flexible and durable antenna mounting solution for standard 1-14 threaded antennas. Ideal for vessels where precise antenna positioning is critical for signal integrity.
How It Compares
| Feature | Shakespeare 4186BP/L206B Nylon Ratchet Mount | Scanstrut ROKK Mini Surface Mount |
|---|---|---|
| Mounting Mechanism | Four-way ratchet with handle | Fixed surface mount |
| Material | Solid Nylon | Composite |
| Thread Size | 1-14 | 1-14 |
| Mounting Flexibility | Deck or side mounting, adjustable | Surface mount only |
| Max Antenna Length (Self-Supporting) | 8' | Not specified |
| Bolt Hole Diameter | 5/16" | Not specified |
| Bolt Hole Spacing (On Center) | 3 x 1-1/2" | Not specified |
Common Concerns Answered
What is the maximum antenna length recommended for the Shakespeare 4186BP/L206B Nylon Ratchet Mount?
The Shakespeare 4186BP/L206B Nylon Ratchet Mount is recommended for antennas up to 8 feet in length when utilized in a self-supporting configuration. Exceeding this limit in self-supporting mode will void the warranty.
Will using an antenna longer than 8 feet void the warranty on this mount?
Yes, using an antenna longer than 8 feet in a self-supporting configuration with the Shakespeare 4186BP/L206B Nylon Ratchet Mount will void the product warranty.
Can the bolt hole spacing be an issue for my installation?
While designed for common installations, the 3 x 1-1/2 inch on-center bolt hole spacing may be restrictive for highly custom or specific aftermarket mounting plates.
Frequently Asked Questions
What type of thread does the Shakespeare 4186BP/L206B Nylon Ratchet Mount use?
The Shakespeare 4186BP/L206B Nylon Ratchet Mount uses a standard 1-14 thread, compatible with most marine antennas.
What are the dimensions of the bolt holes on the Shakespeare 4186BP/L206B Nylon Ratchet Mount?
The bolt holes on the Shakespeare 4186BP/L206B Nylon Ratchet Mount are 5/16 inch in diameter.
Can the Shakespeare 4186BP/L206B Nylon Ratchet Mount be used for side mounting?
Yes, the Shakespeare 4186BP/L206B Nylon Ratchet Mount is designed for both deck and side mounting applications, offering significant installation flexibility.
What material is the Shakespeare 4186BP/L206B Nylon Ratchet Mount made of?
The Shakespeare 4186BP/L206B Nylon Ratchet Mount is constructed from durable, solid nylon material engineered for marine environments.
What is the bolt hole spacing on center for this mount?
The bolt hole spacing on center for the Shakespeare 4186BP/L206B Nylon Ratchet Mount is 3 inches by 1-1/2 inches.
