Shakespeare ART-3 VHF Antenna Tester | Boat Supply Store
Ensure your VHF marine radio system operates at peak efficiency with this comprehensive diagnostic tool. It accurately measures RF output power up to 30 watts and Standing Wave Ratio (VSWR) for your antenna system, with a rated accuracy of 10%. The unique ability to test receiver function, a critical component often overlooked, provides a complete system check for offshore anglers and cruisers navigating Texas coastal waters or beyond.
Key Features
- Test receiver function for complete system verification
- Measure RF output power from 0-30 watts
- Analyze VSWR to identify antenna system impedance mismatches
- Utilize internal battery or 12 VDC ship power for onboard operation
- Experience compact, portable design for easy field use
- Verify battery level with the integrated check
- Constructed from durable die-cast aluminum for marine environments
- Generate a 1000 Hz tone with 3 KHz deviation for testing
Specifications
| Product Specifications | |
|---|---|
| Frequency Range | 155-158 MHz |
| RF Power Scale | 0-30 watts |
| Impedance | 50 ohms |
| Accuracy | 10% |
| Connectors | SO-239 |
| Signal Generator | 3 KHz Deviation Tone: 1000 Hz |
| RF Level | -115 dBM (approx.) |
| Construction | Die-cast aluminum |
Who This Is For
Serious mariners who require rapid and precise verification of their VHF antenna system's output power and VSWR. Ideal for boat owners who prioritize maintaining optimal communication performance without the need for external radio checks.
How It Compares
| Feature | Shakespeare ART-3 VHF Antenna Tester | Competitor |
|---|---|---|
| Receiver Function Test | Yes | No, No |
| Output Power Measurement | Yes (0-30 watts) | No, Yes |
| VSWR Measurement | Yes | Yes, Yes |
| Frequency Range | 155-158 MHz | 1-300 MHz, 1.8-170 MHz |
| Signal Generator Tone | Yes (3 KHz Deviation Tone: 1000 Hz) | No, No |
| Construction | Die-cast aluminum | Plastic/Metal (varies by model), Metal |
Common Concerns Answered
What if I need to test antennas outside the 155-158 MHz range?
The ART-3 is specifically engineered for standard VHF marine frequencies. While its dedicated range ensures precise testing for those bands, users requiring broader spectrum analysis may consider alternative analyzers with extended frequency coverage.
Do I need extra cables for this tester?
The ART-3 utilizes standard SO-239 connectors. For certain VHF radio models, an optional Style 4079 cable may be required to complete the connection between the radio and the tester.
Is the ART-3 difficult to operate on a boat?
No, installation is not required. The ART-3 is a portable diagnostic tool designed for immediate use, connecting directly to your antenna and radio system for quick testing.
Frequently Asked Questions
What specific tests can the Shakespeare ART-3 Antenna Radio Tester perform?
The Shakespeare ART-3 performs three critical tests: receiver function, output power, and VSWR (Voltage Standing Wave Ratio).
How is the Shakespeare ART-3 powered?
The ART-3 is versatile in its power options, operating via its internal battery or directly from your vessel's 12 VDC ship power system.
What is the operational frequency range of the Shakespeare ART-3?
The ART-3 is designed to operate within the 155-158 MHz frequency range, which covers standard marine VHF communications.
Can the Shakespeare ART-3 evaluate the receiver's performance?
Yes, a key distinguishing feature of the ART-3 is its capability to test the receiver function of your VHF radio system, alongside output power and VSWR.
What is VSWR, and how does the ART-3 measure it?
VSWR, or Voltage Standing Wave Ratio, indicates the impedance match between your radio and antenna. High VSWR can reduce transmission efficiency and potentially damage your radio. The ART-3 measures this parameter directly.
