Description
Siren Marine 120V AC Shore Power Relay | Boat Supply Store
Maintain constant awareness of your vessel's 120V AC shore power status with this hardwired relay. It reliably detects the presence and loss of incoming AC power, providing an essential function for integrated marine electrical systems. Featuring a 120VAC coil voltage and a 10A contact current rating, this unit offers a robust solution for monitoring power at the AC distribution panel, ideal for charter vessels operating in the Gulf Coast or offshore fishing platforms requiring dependable power input.
Key Features
- Detects AC shore power presence and loss
- Designed for direct hardwiring to the AC distribution panel
- Reliable 120VAC coil voltage operation
- Robust 10A contact current rating
- Provides integrated monitoring for AC electrical systems
- Hardwired alternative to plug-in sensors
- Essential for uninterrupted vessel power management
- Ensures critical AC power status notifications
Specifications
| Product Specifications | |
|---|---|
| Voltage Type | 120V AC |
| Coil Voltage | 120VAC |
| Contact Current | 10A |
| Installation Type | Hardwired to AC Distribution Panel |
Who This Is For
Boat owners with 120V AC electrical systems requiring direct integration for shore power monitoring. This unit is specifically for individuals prioritizing a hardwired solution over plug-in sensors for their AC distribution panel.
How It Compares
| Feature | Siren Marine 120V AC Shore Power Relay | Blue Sea Systems 7060 M |
|---|---|---|
| AC Shore Power Monitoring | Yes | No, No |
| Voltage Type | 120V AC | 12/24V DC, 12/24V DC |
| Contact Current Rating | 10A | 60A Continuous, 200A Continuous |
| Primary Function | AC Shore Power Detection | DC Battery Combining, DC Battery Combining |
| Installation Type | Hardwired to AC Panel | Hardwired to DC System, Hardwired to DC System |
Common Concerns Answered
I'm not comfortable with electrical work, can I still use this?
While this relay offers robust monitoring, installation requires basic electrical wiring knowledge to connect to your AC distribution panel. Professional installation is strongly recommended if you are unfamiliar with AC marine electrical systems to ensure safety and proper function.
Can this relay be used on boats with 240V AC systems?
No, this specific Siren Marine relay is designed exclusively for 120V AC systems. It cannot be used for 240V AC shore power configurations.
What makes this a better choice than a plug-in sensor?
This wired relay provides a more reliable and integrated solution for monitoring AC shore power status directly at the distribution panel, eliminating potential issues associated with plug-in connections and offering a more permanent installation for critical systems.
Frequently Asked Questions
How does the Siren Marine 120V AC Shore Power Relay detect shore power?
The relay is wired into the AC distribution panel and uses its internal circuitry to detect the presence or absence of a 120V AC signal, indicating whether shore power is connected and active.
What is the difference between the wired relay and the Siren Marine Shore Power Sensor Plug?
The wired relay connects directly to your AC distribution panel for integrated monitoring, offering a permanent hardwired solution. The Shore Power Sensor Plug is a simpler, plug-in device designed for use at the shore power inlet.
What is the maximum current the Siren Marine 120V AC Shore Power Relay can handle?
This relay has a contact current rating of 10A, meaning it is designed to monitor circuits within this current limit.
Is this relay suitable for boats with 240V AC systems?
No, this relay is specifically designed for 120V AC systems only and is not compatible with 240V AC configurations.
What type of boats is this shore power relay designed for?
This relay is designed for any boat operating with a 120V AC shore power system that desires integrated, hardwired monitoring of shore power status at the AC distribution panel.
