Description
Uflex 12" Mechanical Hatchlifter | Boat Supply Store
Effortlessly operate heavy boat hatches with the Uflex Mechanical Hatchlifter, an electromechanical system designed for robust marine environments. It provides a reliable 12" stroke and a maximum load capacity of 1200N for a single actuator, ensuring secure operation of engine boxes or peak tanks. Featuring IP65 ingress protection and UL1500/ISO8846 safety certifications, this unit guarantees ignition protection and durability for offshore applications.
Key Features
- Automated operation for heavy hatches, eliminating manual strain.
- Maintenance-free electromechanical design for long-term reliability.
- Self-locking mechanism maintains hatch position securely.
- Emergency manual override provides essential functionality during power loss.
- Marine-grade materials ensure resistance to corrosion and harsh conditions.
- IP65 rated for protection against dust and low-pressure water jets.
- Ignition Protected (12VDC models) for safe operation in potentially explosive atmospheres.
- UL1500 and ISO8846 approved for adherence to stringent marine safety standards.
Specifications
| Product Specifications | |
|---|---|
| Stroke Length | 12 inches (300mm) |
| Voltage | 12V DC |
| Full Closed Length | 677mm (26.6 inches) |
| External Diameter | 48mm (1.9 inches) |
| Max Load (Single) | 1200N |
| Max Load (Dual) | 2400N |
| Speed (No Load) | 25mm/sec |
| Speed (Max Load) | 17mm/sec |
| Current (12V Single) | 10A |
| Current (24V Single) | 5A |
| Current (12V Dual) | 20A |
| Current (24V Dual) | 10A |
| IP Rating | IP65 |
| Ignition Protected | Yes (12VDC models) |
| Safety Approvals | UL1500, ISO8846 |
Who This Is For
Owners of pleasure boats requiring a dependable, automated system for managing heavy engine hatches, peak tanks, or hatch beams. Ideal for those prioritizing enhanced safety, user convenience, and long-term durability in demanding marine environments.
How It Compares
| Feature | Uflex 12" Mechanical Hatchlifter | Competitor |
|---|---|---|
| Type | Electromechanical Actuator | Mechanical Spring Lift, Electromechanical Actuator |
| Voltage | 12V DC | N/A (Mechanical), 12V DC |
| Stroke Length | 12" (300mm) | — |
| Max Load (Single Installation) | 1200N (265 lbs) | N/A (Spring assisted, not rated for powered lift), 1000N |
| Manual Override | Yes (Stainless steel telescopic ram) | N/A, Likely, but not explicitly detailed in brief specs |
| Ignition Protected | Yes (12VDC models) | N/A, Not explicitly stated in brief specs |
| IP Rating | IP65 | N/A, Not explicitly stated in brief specs |
Common Concerns Answered
Are there common issues with the Uflex Mechanical Hatchlifter?
Some users report occasional issues with electrical connections if they are not properly sealed against moisture ingress, highlighting the importance of diligent sealing during installation.
Is the Uflex Mechanical Hatchlifter expensive?
While its initial investment may be higher than basic mechanical solutions, the advanced features, durability, and safety certifications provide superior long-term value and reliability for critical hatch operations.
Is electrical installation complex?
The electromechanical nature requires basic electrical wiring knowledge. However, the included mounting hardware and clear design facilitate straightforward installation for those with foundational marine electrical system familiarity.
Frequently Asked Questions
What is the maximum load capacity of the Uflex Mechanical Hatchlifter 12" STK Fast?
The Uflex Mechanical Hatchlifter 12" STK Fast has a maximum load capacity of 1200N for a single unit installation and 2400N for a dual unit installation.
Can the Uflex Mechanical Hatchlifter be operated manually in case of power failure?
Yes, the Uflex Mechanical Hatchlifter is equipped with an emergency manual opening device, allowing for operation even during a power failure.
What is the stroke length of the Uflex Mechanical Hatchlifter 12" STK Fast?
The stroke length of the Uflex Mechanical Hatchlifter 12" STK Fast is 12 inches (300mm).
Is the Uflex Mechanical Hatchlifter 12" STK Fast ignition protected?
Yes, the 12VDC models of the Uflex Mechanical Hatchlifter 12" STK Fast are ignition protected, meeting UL1500 and ISO8846 standards.
What is the IP rating of the Uflex Mechanical Hatchlifter 12" STK Fast?
The Uflex Mechanical Hatchlifter 12" STK Fast is IP65 rated, providing protection against dust ingress and low-pressure water jets.
