Description
Veratron GO GPS Receiver NMEA 2000 | Boat Supply Store
For boaters demanding precise real-time positional data, this NMEA 2000 certified GPS receiver delivers multi-system GNSS support including GPS, GLONASS, and GALILEO. Its rapid 10Hz update rate provides heading and speed information with exceptional frequency, essential for offshore navigation or precise docking maneuvers. Measuring a mere 60.7 mm x 18.9 mm, its compact, IPX7 weatherproof design ensures robust performance even in harsh marine environments, drawing power directly from the NMEA 2000 backbone without additional wiring.
Key Features
- NMEA 2000 Certified for seamless network integration.
- Multi-GNSS Support with GPS, GLONASS, and GALILEO for superior accuracy.
- Fast 10Hz Update Rate delivers rapid position, speed, and heading data.
- Compact Footprint (60.7 mm x 18.9 mm) for versatile installation.
- IPX7 Water Resistance ensures durability in wet conditions.
- Direct NMEA 2000 Power eliminates the need for separate power connections.
- 72-Channel Receiver for quick satellite acquisition.
- OceanLink Bezel Compatible for customizable aesthetic integration.
Specifications
| Product Specifications | |
|---|---|
| Receiver Type | 72-channel |
| GNSS Support | GPS, GLONASS, GALILEO |
| Update Rate | 10Hz |
| Water Resistance | IPX7 |
| Dimensions (Diameter x Height) | 60.7 mm x 18.9 mm |
| Power Source | NMEA 2000 Backbone |
| Certifications | NMEA 2000 |
| SAW Filter | Integrated front-end SAW band-pass filter |
| Bezel Compatibility | OceanLink 52MM Bezels |
Who This Is For
Boaters requiring accurate, real-time position, speed, and heading data integrated into their NMEA 2000 network. Ideal for users of compact displays like the Veratron Go Data or anyone upgrading an existing NMEA 2000 system with a high-performance GPS source.
How It Compares
| Feature | Veratron GO GPS Receiver NMEA 2000 | Competitor |
|---|---|---|
| Update Rate | Up to 10Hz | 10 Hz |
| GNSS Support | GPS, GLONASS, GALILEO | GPS, GLONASS, Galileo, QZSS, BeiDou |
| Water Resistance | IPX7 | IPX7 |
| NMEA 2000 Certified | Yes | Yes |
| Dimensions (D x H) | 60.7 mm x 18.9 mm | Approx. 90 mm x 40 mm |
Common Concerns Answered
Will this tiny receiver provide accurate data?
Yes, the Veratron GO GPS Receiver utilizes a 72-channel receiver with multi-GNSS support (GPS, GLONASS, GALILEO) and an integrated SAW band-pass filter for excellent accuracy and noise immunity, even in challenging signal environments.
Is it difficult to install if I'm not an electronics expert?
Installation difficulty is rated 2/5. It connects directly to your existing NMEA 2000 backbone, requiring basic knowledge of network termination and cable routing. No external power connection is necessary, simplifying setup considerably.
What if I don't have an NMEA 2000 network yet?
This receiver is designed to integrate seamlessly into an existing NMEA 2000 network. If you do not have one, you will need to establish a basic NMEA 2000 backbone first, which includes a power-T, terminators, and necessary cabling to connect this device.
Frequently Asked Questions
What is the update rate of the Veratron GO GPS Receiver?
The Veratron GO GPS Receiver features a fast 10Hz update rate, providing positional data ten times per second.
Is the Veratron GO GPS Receiver NMEA 2000 certified?
Yes, the Veratron GO GPS Receiver is NMEA 2000 certified, ensuring compatibility with other devices on your marine network.
What GNSS systems does the Veratron GO GPS Receiver support?
It supports multiple GNSS systems, including GPS, GLONASS, and GALILEO, for enhanced accuracy and reliability.
What is the position accuracy of the Veratron GO GPS Receiver?
While specific accuracy in meters is not provided, its multi-GNSS support and 72-channel receiver provide highly precise and reliable positional data for navigation.
Does the Veratron GO GPS Receiver require external power?
No, the Veratron GO GPS Receiver draws its power directly from the NMEA 2000 backbone, eliminating the need for a separate power connection.
