Victron ANL-Fuse 500A/80V for 48V Systems | Boat Supply Store
Protecting high-amperage 48V DC marine electrical systems necessitates a fuse with exceptional breaking capacity. The Victron ANL-Fuse 500A/80V provides this critical protection, boasting a short-circuit breaking capability exceeding standard MEGA fuses. With a robust 500A rating and 80V limit, it ensures component integrity and operational safety for demanding applications like large cruising catamarans or advanced sportfishing vessels operating in challenging offshore environments.
Key Features
- Fast-acting bolt-down design for rapid circuit interruption
- Superior short-circuit breaking capability compared to standard MEGA fuses
- High current capacity rated for 500 amps for heavy loads
- Broad voltage range rated for up to 80 volts
- Optimized for 48V systems, ensuring precise protection
- Low voltage drop of approximately 100 mΩ for efficiency
- Minimal cold resistance of 0.25 mΩ reduces power loss
- Renowned Victron Energy reliability for critical marine applications
Specifications
| Product Specifications | |
|---|---|
| Maximum Current Rating | 500 amps |
| Maximum Voltage Rating | 80 volts |
| Designed For | 48V Systems |
| Fuse Type | ANL |
| Short-Circuit Breaking Capability | Higher than MEGA fuses |
| Approximate Voltage Drop | 100 mΩ |
| Cold Resistance | 0.25 mΩ |
| Form Factor | Single Bolt-Down Fuse |
Who This Is For
This fuse is engineered for marine electrical system designers, installers, and owners of 48V DC systems requiring robust, high-current protection. It is particularly suited for those prioritizing enhanced safety and component longevity in demanding marine environments.
How It Compares
| Feature | Victron ANL-Fuse 500A/80V for 48V Systems | Blue Sea Systems ANL Fuse 500A 80V |
|---|---|---|
| Max Current Rating | 500 amps | 500 amps |
| Max Voltage Rating | 80 volts | 80 volts |
| Fuse Type | ANL | ANL |
| Short-Circuit Breaking Capability | Higher than MEGA fuses | Not explicitly stated as higher than MEGA fuses |
| Approximate Voltage Drop | 100 mΩ | null |
| Cold Resistance | 0.25 mΩ | null |
Common Concerns Answered
Is the Victron ANL-Fuse 500A/80V as reliable as other brands?
Customer sentiment is overwhelmingly positive, highlighting Victron's reputation for reliability and high-performance protection in demanding marine electrical systems, justifying its investment for critical 48V applications.
Why is the price higher than some generic alternatives?
While the price point may be higher, this is attributed to the superior short-circuit breaking capability and Victron's established quality standards, offering enhanced safety and component protection crucial for 48V systems.
Is availability a concern for this specialized fuse?
Availability can sometimes be limited due to its specialized nature, but its unique advantages in high-current 48V protection make it a sought-after component for serious marine electrical installations.
Frequently Asked Questions
What is the maximum voltage rating for the Victron ANL-Fuse 500A/80V?
The maximum voltage rating for this Victron ANL fuse is 80 volts.
What is the current rating of this Victron ANL fuse?
This Victron ANL fuse has a maximum current rating of 500 amps.
What is the approximate voltage drop across this fuse?
The approximate voltage drop across the Victron ANL-Fuse 500A/80V is 100 mΩ.
Is this fuse suitable for 12V or 24V systems?
While the fuse is rated for 80 volts, it is specifically designed and optimized for 48V DC systems where its high breaking capacity is most beneficial. For 12V or 24V systems, lower amperage and voltage-rated fuses are typically more appropriate and cost-effective.
How does the Victron ANL fuse compare to a MEGA fuse?
The Victron ANL-Fuse 500A/80V offers a superior short-circuit breaking capability compared to standard MEGA fuses, providing enhanced protection for critical 48V marine electrical circuits.
