Victron Centaur 12V 60A 3-Bank Charger | Boat Supply Store
Maintain critical battery systems for extended offshore voyages or demanding operational schedules with the Victron Centaur Charger. This robust unit delivers 60 AMPs of charging current across three isolated 12 VDC banks, ensuring each battery receives optimal power. Its universal 90-265 VAC input range accommodates diverse power sources, while integrated temperature compensation maintains battery health by automatically adjusting charge voltage based on ambient temperature, a critical factor for battery longevity in fluctuating marine environments.
Key Features
- Uncompromising Quality: Corrosion-resistant construction with epoxy powder-coated aluminum cases and acrylic-coated circuit boards ensures longevity in harsh marine environments.
- Optimal Battery Health: Advanced three-stage charging (Bulk, Timed, Float) combined with temperature compensation provides precise charging for flooded, Gel, and AGM batteries.
- Versatile Power Input: Universal 90-265 VAC input supports global AC power sources, and it can also operate on DC supply (AC-DC and DC-DC functionality).
- Full Current Output: Three isolated outputs allow each bank to receive the full rated 60 AMP current simultaneously.
- Durable Construction: Stainless steel fixings and a drip shield offer superior protection against the elements and saltwater intrusion.
- Automatic Protection: Temperature sensors prevent overheating by automatically reducing output if power components exceed specified limits.
- Selectable Charge Profiles: DIP switch allows easy selection of optimized charge and float voltages for different battery chemistries.
- Reliable Performance: Engineered by Victron Energy for consistent and dependable battery charging across a wide spectrum of conditions.
Specifications
| Product Specifications | |
|---|---|
| Output Voltage | 12 VDC |
| Output Amperage | 60 AMP |
| Number of Banks | 3 |
| AC Input Voltage Range | 90-265 VAC |
| Charging Algorithm | 3-Stage (Bulk, Timed, Float) |
| Temperature Compensation | Yes (-2 mV/°C per cell) |
| Corrosion Resistance | High (Epoxy coated case, acrylic coated boards, stainless steel fixings) |
| DC Supply Operation | Yes |
| Output Current per Bank | Full rated current |
Who This Is For
Marine enthusiasts and boat owners demanding reliable and robust battery charging for 12V systems. Fleet operators requiring versatile charging solutions capable of managing multiple battery banks in diverse environmental conditions will also benefit.
How It Compares
| Feature | Victron Centaur 12V 60A 3-Bank Charger | Competitor |
|---|---|---|
| Output Voltage | 12 VDC | 12 VDC |
| Output Amperage | 60A | 60A |
| Number of Banks | 3 | 3 |
| AC Input Voltage Range | 90-265 VAC | 100-240 VAC |
| Charging Algorithm | 3-Stage (Bulk, Timed, Float) | 5-Stage (Conditioning, Bulk, Absorption, Equalization, Float), 3-Stage |
| Temperature Compensation | Yes (-2 mV/°C per cell) | Yes |
| Corrosion Resistance | High (Epoxy coated case, acrylic coated boards, stainless steel fixings) | High |
| DC Supply Operation | Yes | No |
Common Concerns Answered
Is the 3-stage charging algorithm sufficient for all battery types?
The Victron Centaur Charger utilizes a proven 3-stage charging algorithm (Bulk, Timed, Float) with selectable profiles for Flooded, Gel, and AGM batteries, ensuring optimal charging for common marine chemistries. While some competitors offer 5-stage algorithms for highly specialized battery management, this unit provides robust and reliable charging for the vast majority of marine applications, prioritizing battery longevity and performance.
What is the California P65 warning and its relevance?
The California P65 warning is a standard regulatory disclaimer required by the state of California for products that may contain certain chemicals. This is a general warning and does not indicate a specific hazard unique to this product's marine functionality or performance. Victron Energy complies with all applicable regulations, and this warning is a standard part of product disclosures.
How does the temperature compensation work?
The Victron Centaur Charger incorporates temperature compensation that automatically reduces the charge voltage as battery temperature increases, and vice-versa. This prevents overcharging in hot conditions and ensures adequate charging in cold conditions, significantly contributing to the battery's lifespan and optimal performance. The compensation is set at -2 mV/°C per cell.
Frequently Asked Questions
What is the charging algorithm of the Victron Centaur Charger?
The Victron Centaur Charger employs a three-stage charging algorithm consisting of Bulk, Timed, and Float stages. This intelligent process ensures batteries are charged quickly and efficiently while maintaining their health.
Can the Victron Centaur Charger be used with different battery types (Flooded, Gel, AGM)?
Yes, the Victron Centaur Charger is specifically designed for use with Flooded Lead-acid, Gel, and AGM batteries. A DIP switch allows for easy selection of the optimum charge and float voltages for each battery chemistry.
What is the AC input voltage range for the Victron Centaur Charger?
The Victron Centaur Charger features a universal AC input voltage range of 90-265 VAC, making it suitable for use with a wide variety of power sources globally.
How many battery banks can the Victron Centaur Charger charge simultaneously?
The Victron Centaur Charger is a 3-bank charger, meaning it can charge three separate battery banks concurrently, with each bank receiving the full rated current.
Does the Victron Centaur Charger have temperature compensation for charging?
Yes, the Victron Centaur Charger includes temperature compensation, which automatically adjusts the charge voltage based on battery temperature to optimize charging efficiency and battery longevity. The compensation is rated at -2 mV/°C per cell.
