Description
Victron GX Tank 140 Tank Monitor | Boat Supply Store
Navigate the complexities of fluid management aboard your vessel with precise level monitoring. This unit supports up to four distinct tank sensors utilizing either 4-20 mA or 1-10 VDC output signals, providing crucial data for fuel, potable water, or black water systems. It seamlessly integrates with the Victron GX system via a single USB connection for both power and data transmission, offering configurable damping from 1 to 60 seconds to ensure stable readings even in rough seas. Real-time fault detection for sensors and wiring alerts operators to potential issues before they become critical, enhancing operational safety and efficiency on vessels ranging from sportfishers to cruising catamarans.
Key Features
- Monitor up to 4 independent tank level sensors
- Compatible with industry-standard 4-20 mA and 1-10 VDC sensors
- Seamlessly integrates with Victron GX devices via USB for power and data
- Provides 24V power for up to two connected sensors
- Configurable limits for precise fluid level alerts
- Adjustable damping (1-60s) ensures stable, reliable readings
- Detects sensor/wiring faults with integrated alarm functionality
- Transmits data to NMEA 2000 network when connected to a GX Device
Specifications
| Product Specifications | |
|---|---|
| Monitors up to | 4 tank level sensors |
| Sensor Input Types | 4-20 mA, 1-10 VDC |
| Connectivity | USB to GX devices |
| Sensor Power | 2x 24V sender power, 2x requires external power |
| Configurable Damping | 1-60 seconds |
| Fault Detection | Sensor/wiring faults |
| Data Output | NMEA 2000 via GX Device |
Who This Is For
Marine vessel owners and operators requiring accurate, integrated monitoring of multiple fluid tanks. Ideal for those already utilizing or planning to integrate a Victron Energy GX system for comprehensive vessel management.
How It Compares
| Feature | Victron GX Tank 140 Tank Monitor | Competitor |
|---|---|---|
| Number of Sensors Monitored | Up to 4 | Depends on connected sensors and network configuration, Up to 8 analog inputs |
| Sensor Input Types | 4-20 mA, 1-10 VDC | Requires specific Garmin sensors or compatible NMEA 2000 sensors, 0-5V, 4-20mA, resistive, frequency |
| Power Source | USB from GX Device | 12-24 VDC, 10-35 VDC |
| Data Output | USB to GX Device (NMEA 2000 via GX Device) | NMEA 2000, NMEA 2000 |
Common Concerns Answered
Are tank sensors included with the Victron GX Tank 140?
No, tank sensors are sold separately. This unit is designed for flexible integration with a variety of 4-20 mA or 1-10 VDC sensors, allowing you to choose the best option for your specific tank requirements.
Does the Victron GX Tank 140 work as a standalone unit?
The Victron GX Tank 140 requires a Victron GX device, such as the Cerbo GX, for full functionality, including power, data transmission, and display integration. This ensures seamless operation within the Victron ecosystem.
I'm concerned about unreliable readings from my tank sensors. How does this unit address that?
The Victron GX Tank 140 features configurable damping from 1 to 60 seconds, which smooths out fluctuating sensor signals caused by vessel movement, ensuring stable and accurate fluid level readings.
Frequently Asked Questions
What types of tank level sensors are compatible with the Victron GX Tank 140?
The Victron GX Tank 140 is compatible with tank level sensors that output either a 4-20 mA or a 1-10 VDC signal.
How many sensors can the Victron GX Tank 140 monitor?
The Victron GX Tank 140 can monitor up to four (4) tank level sensors simultaneously.
How is the Victron GX Tank 140 powered?
The unit is powered and receives data via a single USB cable connected to a Victron GX device.
What is the damping setting on the Victron GX Tank 140 used for?
The damping setting (configurable from 1 to 60 seconds) is used to stabilize sensor readings by averaging out rapid fluctuations, providing a more consistent and reliable display of fluid levels, especially in dynamic marine environments.
Does the Victron GX Tank 140 detect faulty sensors or wiring issues?
Yes, the Victron GX Tank 140 includes fault detection capabilities that identify issues with connected sensors or wiring, alerting the user to potential problems through alarms.
