Description
Victron Orion 24/12-30 DC-DC Converter IP20 | Boat Supply Store
This converter efficiently steps down 24V DC to 12V DC, solving power incompatibility issues in modern vessels. It delivers a stable 30A continuous output, ideal for supplying 12V electronics from a 24V battery bank. The adjustable output voltage feature allows it to function as a dedicated battery charger for 12V systems, ensuring optimal battery health. Its IP20 rating necessitates installation in a protected compartment, suitable for use on offshore fishing vessels or charter yachts operating in demanding conditions.
Key Features
- Reliable 24V to 12V DC-DC power conversion
- High-current 30A continuous output
- Versatile adjustable output for battery charging
- Scalable paralleling capability up to 5 units
- Protected IP20 rated enclosure
- Convenient remote on/off connector
- Robust Victron Energy engineering
- Marine-ready for demanding environments
Specifications
| Product Specifications | |
|---|---|
| Input Voltage | 24V DC |
| Output Voltage | 12V DC |
| Continuous Output Current | 30A |
| IP Rating | IP20 |
| Features | Remote on/off, adjustable output for battery charging, paralleling capability |
| Paralleling Capability | Up to 5 units |
Who This Is For
This converter is designed for boat owners and marine technicians who require a dependable method to reduce 24V DC power to 12V DC for operating specific onboard equipment or maintaining 12V battery charge within a 24V electrical system. It is an essential component for integrating diverse voltage systems commonly found on larger yachts and commercial vessels.
How It Compares
| Feature | Victron Orion 24/12-30 DC-DC Converter IP20 | Competitor |
|---|---|---|
| Output Current | 30A | 15A |
| Input Voltage | 24V | 24V |
| Output Voltage | 12V | 12V |
| IP Rating | IP20 | IP20 |
| Adjustable Output/Battery Charging | Yes | Yes |
| Paralleling Capability | Yes (up to 5 units) | Yes |
Common Concerns Answered
Will I need to consult the manual for setup?
While the remote on/off feature simplifies wiring, advanced configurations like paralleling units may benefit from referring to the comprehensive manual to ensure optimal performance and understanding of all functionalities.
Can this converter be exposed to water?
The Victron Orion 24/12-30 features an IP20 rating, indicating protection against solid objects larger than 12.5mm but no protection against water ingress. It must be installed in a dry, protected location within the vessel.
Is this converter as reliable as other Victron products?
Victron Energy is renowned for its robust and dependable marine-grade products. Users consistently praise the reliability and performance of Victron converters, particularly in challenging maritime environments.
Frequently Asked Questions
What is the Victron Orion 24/12-30 DC-DC Converter IP20 used for?
This DC-DC converter is used to step down 24V DC input voltage to a stable 12V DC output voltage. This is essential for powering 12V equipment from a 24V battery system or charging a 12V battery within a 24V electrical configuration on a boat.
Can the Victron Orion 24/12-30 be used as a battery charger?
Yes, the Victron Orion 24/12-30 features an adjustable output voltage that allows it to function effectively as a battery charger for 12V batteries, ensuring they are maintained at optimal charge levels.
How can I connect multiple Victron Orion 24/12-30 converters?
Multiple Victron Orion 24/12-30 converters can be paralleled together to achieve a higher total output current. Up to five units can be connected in parallel, requiring appropriate wiring and fusing as detailed in the product manual.
What is the IP rating of the Victron Orion 24/12-30?
The Victron Orion 24/12-30 DC-DC Converter has an IP20 rating. This means it is protected against solid objects greater than 12.5mm in diameter but offers no protection against water, requiring installation in a dry, sheltered area.
How does the remote on/off feature work on the Victron Orion 24/12-30?
The remote on/off connector on the Victron Orion 24/12-30 allows the converter to be controlled by an external switch or signal. This enables you to turn the converter on or off without direct access to the unit, simplifying system integration and power management.
