Description
Wichard Captive Pin D Shackle 10mm | Boat Supply Store
Eliminate the risk of accidental shackle failure on your vessel with this Wichard Captive Pin D Shackle, engineered for critical load-bearing applications. Its robust 316L stainless steel construction ensures exceptional corrosion resistance and structural integrity, boasting a working load limit (WLL) of 2290 lb and a breaking load of 11460 lb. The integrated captive pin design, which locks into indentations, actively combats loosening caused by constant vibration, providing a consistently secure connection ideal for sail furling systems or permanent anchor attachments.
Key Features
- Unparalleled Security: Captive pin design permanently attaches the pin, preventing accidental detachment and loss.
- Vibration Proof: Pin locks into indentations, ensuring it remains secure and does not loosen under constant motion.
- Superior Corrosion Resistance: Forged from high-grade 316L stainless steel for extended lifespan in harsh marine environments.
- Exceptional Strength: Offers robust working load limit of 2290 lb and breaking load of 11460 lb for demanding applications.
- Reliable Connection: Designed for consistent, dependable attachment of blocks, heads, and other essential rigging components.
- Compact and Robust: Engineered for maximum performance without excessive bulk.
- Maneuverability: Facilitates straightforward connection and disconnection when required.
- Long-Term Durability: Built to withstand the rigors of continuous marine use.
Specifications
| Product Specifications | |
|---|---|
| Diameter | 10mm (13/32") |
| Material | 316L Stainless Steel |
| Working Load Limit (WLL) | 2290 lb |
| Breaking Load | 11460 lb |
| Pin Type | Captive |
| Dimension A | 1-19/64" |
| Dimension B | 25/32" |
| Dimension C | 7/16" |
| Dimension D | 53/64" |
| Dimension D diameter | 25/64" |
| Dimension E | 23/64" |
| Dimension F | 2-9/32" |
| Dimension G | 2-3/32" |
Who This Is For
Sailors and boaters demanding the utmost reliability for critical rigging points, such as halyard attachments or lifeline connections, will find this shackle indispensable. Marine professionals requiring hardware that withstands constant vibration and extreme weather conditions will benefit from its engineered security and durability.
How It Compares
| Feature | Wichard Captive Pin D Shackle 10mm | Competitor |
|---|---|---|
| Pin Type | Captive Pin | Screw Pin |
| Material | 316L Stainless Steel | 316 Stainless Steel |
| Working Load Limit (lb) | 2290 | 2000 |
| Breaking Load (lb) | 11460 | 10000 |
| Pin Locking Mechanism | Locks into indentations | Screw thread |
Common Concerns Answered
Is the captive pin difficult to operate?
While occasional difficulty seating the pin fully in its locked position can occur if not aligned perfectly, the captive pin design is engineered for manual operation. Users report it's significantly easier to manage than separate pin systems in challenging conditions.
Why is this shackle more expensive than a standard screw pin shackle?
The elevated price point reflects the advanced engineering and enhanced security of the captive pin mechanism, which prevents accidental loss and loosening due to vibration. This superior reliability and durability offer long-term value and peace of mind for critical rigging applications, outweighing the initial cost difference.
Will the captive pin rust or corrode?
Constructed from Grade 316L stainless steel, this shackle is specifically chosen for its exceptional resistance to corrosion and rust, even in prolonged exposure to saltwater and harsh marine environments, ensuring its integrity and functionality.
Frequently Asked Questions
What is the working load limit (WLL) for the Wichard Captive Pin D Shackle - 10mm?
The working load limit (WLL) for the Wichard Captive Pin D Shackle - 10mm is 2290 lb.
What is the breaking load of this Wichard shackle?
The breaking load of this Wichard Captive Pin D Shackle is 11460 lb.
What material is the Wichard Captive Pin D Shackle made from?
The Wichard Captive Pin D Shackle is forged from high-strength Grade 316L stainless steel.
What are the dimensions of the Wichard Captive Pin D Shackle - 10mm?
Key dimensions include: A: 1-19/64", B: 25/32", C: 7/16", D: 53/64", D diameter: 25/64", E: 23/64", F: 2-9/32", and G: 2-3/32".
Why is the captive pin feature important on this shackle?
The captive pin feature is critical as it ensures the pin remains attached to the shackle body even when opened, preventing accidental loss. Additionally, its locking mechanism resists loosening due to vibrations, maintaining a secure connection.
