Actisense 0183 to N2K Gateway w/PC | Boat Supply Store
Bridge the gap between legacy NMEA 0183 equipment and modern NMEA 2000 networks with this intelligent gateway. It also functions as a dedicated PC interface, supporting data transfer rates up to 230,400 baud for seamless integration with navigation software. The device operates on NMEA 2000 power (9-30V DC) with a low current draw of 62mA @ 9V DC and features robust 1000V Hi-Pot isolation to prevent ground loops, ensuring reliable data flow for critical systems on any vessel.
Key Features
- Integrate legacy NMEA 0183 instruments with NMEA 2000 networks.
- Interface directly with PC applications via USB for data logging and display.
- Achieve bi-directional conversion between NMEA 0183 and NMEA 2000 protocols.
- Benefit from full port isolation (1000V Hi-Pot tested) to eliminate ground loops.
- Utilize advanced configuration options for Tx/Rx lists and transmission rates via Actisense Toolkit.
- Diagnose your NMEA 2000 network with the included FREE NMEA Reader software.
- Ensure durability with IP67 environmental protection and a flame-retardant housing.
- Gain peace of mind with a 3-year warranty, extendable to 5 years upon registration.
Specifications
| Product Specifications | |
|---|---|
| Power Input | NMEA 2000 (9-30V DC) |
| Current Draw | 62mA @ 9V DC |
| Load Equivalent Number (LEN) | 2 |
| NMEA 2000 Port Connector | M12 Male (A coded) |
| NMEA 2000 Baud Rate | 250kbps |
| USB Port Type | Type A |
| USB Baud Rates Supported | 4800 to 230,400 baud |
| USB Cable Length | 1.8m |
| Isolation Voltage | 1000V Hi-Pot tested |
| Enclosure Material | Flame-retardant polycarbonate and PBT |
| Environmental Protection | IP67 |
| Operating Temperature | -25°C to +70°C |
| Warranty | 3-year (extendable to 5 years) |
Who This Is For
Marine electronics installers and boat owners seeking to bridge NMEA 0183 legacy equipment with modern NMEA 2000 systems. Ideal for users who require PC interface for navigation software and data logging from their vessel's electronic network.
How It Compares
| Feature | Actisense 0183 to N2K Gateway w/PC | Actisense NGW |
|---|---|---|
| NMEA 0183 to NMEA 2000 Conversion | Bi-directional | Bi-directional |
| PC Interface | Yes (USB) | No |
| Data Transfer Rate (USB) | Up to 230,400 Baud | Typically less capable |
| NMEA 2000 PGN Support | All available | All available |
| Isolation | Yes (1000V Hi-Pot) | Yes |
Common Concerns Answered
What if I encounter issues with the Actisense NGX-1-USB configuration?
While the Actisense Toolkit offers comprehensive control, some users may find an initial learning curve. For direct support regarding product issues, it is necessary to contact the manufacturer directly, as returns to the original point of purchase are not permitted.
Is the configuration process complex for a novice user?
The Actisense Toolkit, used for configuration, requires a foundational understanding of NMEA protocols and desired data flow, which may present a slight learning curve for those unfamiliar with marine electronics. Basic installation experience is beneficial for optimal setup.
Can I return this product directly to Boat Supply Store if it's defective?
Please be advised that returns for issues with this product must be directed to the manufacturer. This ensures specialized support for technical product concerns, though it requires direct contact with the manufacturer for resolution.
Frequently Asked Questions
What is the primary function of the Actisense NGX-1-USB?
The primary function is to act as an intelligent gateway, bi-directionally converting data between NMEA 0183 and NMEA 2000 networks, while simultaneously serving as a PC interface via USB.
Can the NGX-1-USB connect NMEA 0183 devices to an NMEA 2000 network?
Yes, the NGX-1-USB enables bi-directional conversion, allowing NMEA 0183 devices to send data to and receive data from an NMEA 2000 network.
What PC applications can I interface with using the NGX-1-USB?
You can interface with PC applications such as TimeZero and OpenCPN, as well as any software that supports NMEA 0183 or NMEA 2000 data input via a serial or USB connection.
Does the NGX-1-USB support all NMEA 2000 PGNs?
Yes, the Actisense NGX-1-USB supports all available NMEA 2000 Parameter Group Numbers (PGNs).
What is the data transfer rate of the NGX-1-USB?
The USB connection supports data transfer rates from 4800 baud up to 230,400 baud.
