Actisense USG-2 NMEA 0183 RS422 RS232 Gateway | Boat Supply Store
Reliably interface PCs with legacy marine data networks when PC-to-NMEA ground loops or system faults are a concern. The Actisense USG-2 converts a standard USB port into a bi-directional serial interface supporting NMEA 0183, RS422, and RS232 protocols up to 230400 bps. Its proprietary ISO-Drive™ output and OPTO-isolated input prevent damaging ground loops and protect sensitive PC components from voltage transients common in vessel electrical systems. This robust gateway is essential for integrating navigation software or diagnostic tools with onboard instruments on offshore powerboats or coastal sailboats.
Key Features
- Safely connect PCs to NMEA 0183, RS422, and RS232 systems.
- Prevent ground loops with ISO-Drive™ and OPTO-isolation.
- Protect valuable PC hardware from system faults and voltage spikes.
- Achieve high-speed data transfer up to 230400 bps.
- Ensure environmental durability with IP67 encapsulated electronics.
- Simplify wiring with pluggable screwless connectors and strain relief.
- Monitor connection status via diagnostic and power LEDs.
- Gain broad operating system compatibility with Windows and macOS drivers.
Specifications
| Product Specifications | |
|---|---|
| NMEA 0183 Compatibility | Yes |
| RS422 Compatibility | Yes |
| RS232 Compatibility | Yes |
| USB Interface | USB 2.0 (Type B) |
| Serial Interface | Bi-directional |
| Isolation Technology | ISO-Drive™ (Output), OPTO-isolated (Input) |
| Baud Rate Range | 300 to 230400 bps |
| Environmental Protection | IP67 |
| Connector Type | Pluggable screwless terminal block |
| Power Source | Bus-powered via USB |
| Operating Systems Supported | Windows, macOS |
| Over Voltage Protection | Yes |
| ESD Protection | Yes |
| Short Circuit Protection | Yes |
| Mounting | Bulkhead (Optional DIN rail mount kit available) |
| LED Indicators | Diagnostic, Power |
Who This Is For
Marine electronics installers and boat owners requiring a robust and electrically isolated interface between a PC and NMEA 0183, RS422, or RS232 data networks. System integrators will appreciate the built-in protection against ground loops and voltage faults for reliable PC connectivity in challenging marine environments.
How It Compares
| Feature | Actisense USG-2 NMEA 0183 RS422 RS232 Gateway | NMEA 2000 |
|---|---|---|
| Primary Connectivity | USB to NMEA 0183, RS422, RS232 | Ethernet to NMEA 2000, USB to NMEA 2000 |
| Electrical Isolation | ISO-Drive™ output, OPTO-isolated input | Not applicable (network switch), Implied via NMEA 2000 standard, but not explicitly detailed for PC protection |
| PC Protection | High (protected against over voltage, ESD & short circuits) | Not applicable (network device), Not explicitly detailed for PC protection |
| Baud Rate Range | 300 to 230400 bps | Not applicable (Ethernet), Not applicable |
| Environmental Protection | IP67 | IPX7, Not specified |
Common Concerns Answered
What are the return policies for the Actisense USG-2?
The Actisense USG-2 cannot be returned to the original point of purchase. For any issues or warranty claims, please contact Actisense directly for manufacturer support.
Is the initial setup complicated?
While the physical connection is straightforward due to the pluggable connectors, users may need to pay careful attention to driver installation and serial port configuration. However, the advanced isolation features simplify setup by removing common ground loop concerns.
Is the USG-2 more expensive than standard adapters and is it worth it?
The USG-2 has a higher price point than generic USB-to-serial adapters due to its advanced ISO-Drive™ and OPTO-isolation technologies. This superior electrical isolation, coupled with robust IP67 protection, significantly enhances reliability and prevents damage to connected PCs and marine equipment, making it a critical investment for critical data systems.
Frequently Asked Questions
What is the primary function of the Actisense USG-2?
The primary function of the Actisense USG-2 is to convert a PC's USB port into a bi-directional serial gateway, enabling communication with NMEA 0183, RS422, and RS232 marine data networks.
How does the Actisense USG-2 protect my PC from damage?
The USG-2 protects your PC through its ISO-Drive™ output and OPTO-isolated input, which electrically isolate the PC from the marine network. This prevents ground loops and shields the PC from over voltage, ESD, and short circuit faults.
What NMEA standards does the USG-2 support?
The Actisense USG-2 supports NMEA 0183, as well as RS422 and RS232 serial communication protocols.
Can the USG-2 be used with RS232 devices?
Yes, the Actisense USG-2 is fully compatible with RS232 devices, in addition to NMEA 0183 and RS422.
What is ISO-Drive™ technology?
ISO-Drive™ is Actisense's proprietary output isolation technology designed to prevent ground loops and protect connected equipment by ensuring electrical isolation between the PC and the marine data network.
