Ancor Female NMEA 2000 Field Connector | Boat Supply Store
For boaters requiring precise NMEA 2000 network terminations or field repairs, this Ancor female connector offers a field-serviceable solution. It securely terminates bare NMEA 2000 cable, enabling the creation of custom cable lengths or the replacement of damaged cable ends without pre-made assemblies. Specifically engineered for NMEA 2000 networks, it ensures reliable data transmission for critical marine electronics.
Key Features
- Field serviceable for easy termination and repairs at sea or dockside.
- Securely terminates bare NMEA 2000 cable for robust connections.
- Enables replacement of damaged NMEA 2000 cable ends, extending equipment life.
- Specifically designed for reliable operation within NMEA 2000 networks.
- Offers flexibility in creating custom cable lengths for optimized installations.
- Reduces reliance on pre-made cables, saving time and resources.
- Cost-effective solution for maintaining network integrity on any vessel.
- Facilitates essential network troubleshooting and modifications.
Specifications
| Product Specifications | |
|---|---|
| Brand | Ancor |
| Connector Type | NMEA 2000 |
| Gender | Female |
| Serviceability | Field Serviceable |
| MPN | 270109 |
| SKU | CWR80188 |
Who This Is For
Marine electronics installers and boat owners performing DIY repairs can utilize this connector for creating custom NMEA 2000 cable runs or repairing existing connections. Technicians working with NMEA 2000 networks will find it invaluable for adapting bulk cable to specific vessel requirements.
How It Compares
| Feature | Ancor Female NMEA 2000 Field Connector | Competitor |
|---|---|---|
| Connector Type | NMEA 2000 | Micro-C |
| Serviceability | Field Serviceable | Field Installable |
| Gender | Female | Female |
Common Concerns Answered
I'm worried about achieving a reliable connection for my NMEA 2000 network.
The Ancor field serviceable connector is engineered to securely terminate bare NMEA 2000 cable, ensuring a robust connection when properly installed. Following the specific stripping and termination guidelines is crucial for optimal network performance.
What if water gets into the connector on my boat?
While designed for marine environments, proper sealing of the connector housing after termination is critical to prevent water ingress. Ensure all seals are correctly positioned and the connector is fully secured.
Is field termination difficult for NMEA 2000 cable?
This connector is designed for field serviceability, but it does require careful attention to detail during the stripping and termination process. Familiarity with NMEA 2000 wiring standards and precise execution will yield the best results.
Frequently Asked Questions
What is an NMEA 2000 field serviceable connector?
A field serviceable connector, like this Ancor model, allows you to terminate bare NMEA 2000 cable directly on your vessel, enabling custom cable lengths or repairs without needing to send cable away or use pre-made, fixed-length options.
How do I terminate bare NMEA 2000 cable with this connector?
The process involves carefully stripping the cable jacket and insulation to expose the individual wires, then precisely connecting each wire to its corresponding pin within the connector housing, followed by secure closure of the connector.
Can this connector be used to replace a damaged NMEA 2000 cable end?
Yes, this connector is ideal for replacing a damaged or corroded end of an existing NMEA 2000 cable, allowing you to salvage the cable run rather than replacing the entire length.
What tools are needed to install an Ancor NMEA 2000 Field Serviceable Connector?
You will typically need a sharp blade for precise cable stripping, wire strippers for the individual conductors, and a small tool to ensure firm connection of the wires to the connector pins. A crimping tool may be recommended for specific models.
Is this connector waterproof and suitable for marine environments?
The connector itself is designed for marine use, but it is crucial to ensure a proper seal upon installation. The termination must be completed correctly and the housing secured to maintain its water-resistant integrity in the challenging marine environment.
