Description
Garmin NMEA 2000 Field Connector | Boat Supply Store
Enable precise NMEA 2000 network configurations and field repairs with this Garmin female field installable connector, offering superior flexibility and cost-effectiveness over pre-terminated cabling for specialized lengths. This connector facilitates custom network builds, essential for integrating sonar, GPS, and autopilot systems on vessels ranging from sportfishers to cruising catamarans operating in challenging coastal environments. It provides a robust, sealed connection point allowing technicians to craft network runs perfectly matched to vessel layout requirements.
Key Features
- Create custom NMEA 2000 network lengths for precise installations
- Repair existing NMEA 2000 networks in the field with confidence
- Achieve professional-grade connections in marine environments
- Utilize a standard female connector for broad compatibility
- Ensure network integrity with ruggedized construction
- Reduce costs by avoiding excess cable length from pre-made options
- Integrate seamlessly with existing NMEA 2000 components
- Simplify complex network routing for specialized applications
Specifications
| Product Specifications | |
|---|---|
| Connector Type | Female |
| MPN | 010-11095-00 |
| Certified | NMEA 2000 Certified |
Who This Is For
Ideal for marine electronics installers requiring precise cable lengths and for boat owners undertaking DIY network upgrades. Technicians will appreciate the ability to construct or extend NMEA 2000 networks efficiently.
How It Compares
| Feature | Garmin NMEA 2000 Field Connector | Competitor |
|---|---|---|
| Connector Type | Female | Female, Female |
| NMEA 2000 Certified | Yes | Yes, Yes |
Common Concerns Answered
What tools are required for installation?
Proper installation necessitates specific crimping tools and a method for ensuring perfect sealing to prevent water ingress, which can be a learning curve for novice installers.
Is this connector difficult to install?
While functional, users report that achieving a flawless seal and correct crimp can be fiddly, demanding careful attention to detail for reliable, long-term performance in a marine setting.
Are there common failure points?
Occasional issues with water ingress have been noted by some users, highlighting the critical importance of precise crimping and sealing techniques during the installation process to maintain network integrity.
Frequently Asked Questions
What is a Garmin NMEA 2000 Field Installable Connector?
This device is a female connector designed to terminate an NMEA 2000 cable in the field, allowing for custom cable lengths and connections without relying on pre-made, fixed-length cables.
How do I install a Garmin NMEA 2000 Field Installable Connector?
Installation involves stripping the NMEA 2000 cable, preparing the wires, properly seating them into the connector terminals, crimping them securely, and then sealing the connector body according to the manufacturer's instructions.
What is NMEA 2000?
NMEA 2000 is a standardized communication protocol for marine electronic devices, enabling them to share data such as GPS position, speed, depth, engine data, and autopilot commands across a single backbone network.
Is this connector compatible with all NMEA 2000 networks?
Yes, as an NMEA 2000 certified component, this connector adheres to the standard and is designed to be compatible with any compliant NMEA 2000 network, regardless of the primary manufacturer.
What tools are needed to install this connector?
You will require specialized NMEA 2000 crimping tools, wire stripping tools, and potentially a heat gun or sealant gun depending on the specific termination method and environmental sealing requirements.
