Blue Sea 5510E Dual Circuit Battery Switch | Boat Supply Store
Securely manage power distribution for twin battery systems on gasoline-powered vessels with the Blue Sea 5510E e-Series Dual Circuit Battery Switch. This CE Marked and ignition-protected unit meets stringent ABYC requirements, ensuring safety aboard boats where fuel vapors may be present. It features robust 3/8 - 16 tin-plated copper studs, each 7/8" in length, accommodating standard ring terminals for reliable connections in coastal Texas waters or offshore cruising.
Key Features
- Switch between two battery banks or combine them for increased cranking power.
- Ignition protected for safe installation on gasoline-powered boats.
- Meets ABYC standards for verified marine electrical safety.
- CE Marked for compliance with European safety regulations.
- Versatile mounting options for surface or rear panel installation.
- Durable 3/8 - 16 tin-plated copper studs resist corrosion.
- Tactile knob provides clear position indication by feel.
- Reliable circuit isolation and connection control.
Specifications
| Product Specifications | |
|---|---|
| Brand | Blue Sea Systems |
| Model | 5510E e-Series |
| Circuit Type | Dual Circuit ON-OFF-BOTH-OFF |
| Ignition Protected | Yes |
| ABYC Compliance | Yes |
| CE Marked | Yes |
| Continuous Amperage Rating | 350 Amps |
| Intermittent Amperage Rating (5 min) | 400 Amps |
| Cranking Amperage Rating (30 sec) | 600 Amps |
| Stud Size | 3/8"-16 |
| Stud Length | 7/8" |
| Terminal Type Accepted | 3/8" and M10 Ring Terminals |
| Mounting | Surface or Rear Panel |
Who This Is For
This battery switch is designed for boat owners and marine technicians who require a robust and certified solution for managing dual battery systems, particularly on gasoline-powered vessels. It provides essential safety features and reliable operation for critical electrical functions.
How It Compares
| Feature | Blue Sea 5510E Dual Circuit Battery Switch | Competitor |
|---|---|---|
| Circuit Type | Dual Circuit | Single Circuit |
| Ignition Protected | Yes | No |
| ABYC Compliance | Yes | Yes |
| Stud Size | 3/8"-16 | 3/8"-16 |
| Mounting Options | Surface or Rear Panel | Surface Mount |
Common Concerns Answered
Will the stud length accommodate multiple large gauge cables?
The 7/8" stud length is designed for standard marine ring terminals. For connecting multiple large gauge cables, consider using shorter terminal lugs or an appropriately sized bus bar if space is limited.
Is this switch powerful enough for high-demand systems?
The Blue Sea 5510E offers continuous, intermittent, and cranking amperage ratings of 350A, 400A, and 600A respectively, suitable for most standard marine applications. For extremely high-draw systems, Blue Sea Systems offers switches with higher amperage capabilities.
Are there any known reliability issues?
Customer sentiment is generally positive, with users appreciating the switch's reliability and safety features. As with any marine electrical component, proper installation and maintenance are crucial for long-term performance.
Frequently Asked Questions
What is the maximum amperage rating for the Blue Sea 5510E battery switch?
The Blue Sea 5510E has a continuous amperage rating of 350 Amps, an intermittent rating of 400 Amps (5 minutes), and a cranking rating of 600 Amps (30 seconds).
Can the Blue Sea 5510E battery switch be used on a gasoline-powered boat?
Yes, the Blue Sea 5510E is ignition protected, making it safe for installation aboard gasoline-powered boats.
What type of ring terminals are compatible with the Blue Sea 5510E battery switch studs?
The 3/8"-16 tin-plated copper studs are compatible with both 3/8" and M10 size marine-grade ring terminals.
Does the Blue Sea 5510E battery switch meet ABYC standards?
Yes, the Blue Sea 5510E meets American Boat and Yacht Council (ABYC) requirements, ensuring it adheres to industry safety and performance standards.
How is the Blue Sea 5510E battery switch mounted?
The switch features a versatile design allowing for either surface mounting or rear panel mounting, providing flexibility during installation.
