Description
Blue Sea 6010200 Dual Battery Switch | Boat Supply Store
Ensure reliable power distribution for demanding marine electrical systems with the Blue Sea 6010200 Dual Circuit Battery Switch. This m-Series unit simultaneously switches two isolated battery banks, supporting a robust 300A continuous rating and a 1000A cranking rating for 10 seconds. It is engineered to accommodate 4/0 AWG cables, crucial for high-draw applications like offshore fishing vessels operating in the Gulf of Mexico.
Key Features
- Simultaneously switches two isolated battery banks for efficient power management.
- Dual circuit design provides dedicated control over independent power sources.
- 300A continuous rating ensures reliable performance under sustained high loads.
- 1000A cranking rating (10 sec) delivers ample power for engine starts.
- Accommodates 4/0 AWG cables, supporting high-amperage circuits.
- 3/8"-16 terminal studs offer secure and high-conductivity connections.
- Compact m-Series design integrates seamlessly into marine electrical panels.
- UL Listed for verified safety and reliability in marine environments.
Specifications
| Product Specifications | |
|---|---|
| Switch Type | Dual Circuit |
| Positions | 2 |
| Max Voltage | 32V DC |
| Continuous Rating | 300A |
| Intermittent Rating | 450A (5 min) |
| Cranking Rating (10 sec) | 1000A |
| Cranking Rating (1 min) | 650A |
| Battery Inputs | 2 |
| Cable Gauge Accommodation | 4/0 AWG |
| Cable Clearance | 1.12in |
| Mounting Screw Size | #10 |
| Terminal Stud Size | 3/8"-16 |
| Weight | 0.80lb |
| Color | Black |
Who This Is For
Boat owners and marine technicians requiring independent management of two battery banks for vessels with significant electrical demands. Ideal for those with extensive electronics, multiple engines, or high-power accessories.
How It Compares
| Feature | Blue Sea 6010200 Dual Battery Switch | Blue Sea Systems 6006 ML |
|---|---|---|
| Switch Type | Dual Circuit | Single Circuit |
| Continuous Rating | 300A | 350A |
| Cranking Rating (10 sec) | 1000A | 1200A |
| Battery Inputs | 2 | 1 |
| Terminal Stud Size | 3/8"-16 | 3/8"-16 |
Common Concerns Answered
Is it difficult to get the right torque on the terminal studs?
While some users have noted difficulty achieving proper torque without specialized tools, ensuring the use of appropriately sized wrenches and a torque wrench when possible will mitigate this. The 3/8"-16 terminal studs are standard for high-amperage connections.
Will 4/0 AWG cables fit easily?
The switch is designed to accommodate 4/0 AWG cables, offering 1.12 inches of clearance. However, users may find the cable clearance tight with certain lug types, requiring careful planning of cable entry and lug selection.
Is the price a concern for budget-conscious boaters?
While the initial investment is a consideration, the Blue Sea 6010200's robust construction, high amperage ratings (300A continuous, 1000A cranking), and dual-circuit functionality offer significant value for reliable marine power management, justifying the price for critical systems.
Frequently Asked Questions
What is the continuous amperage rating for the Blue Sea 6010200 battery switch?
The Blue Sea 6010200 battery switch has a continuous amperage rating of 300A.
Can the Blue Sea 6010200 battery switch combine two battery banks?
No, the Blue Sea 6010200 battery switch is designed to switch between two isolated battery banks, not combine them.
What is the maximum voltage supported by the Blue Sea 6010200 battery switch?
The maximum voltage supported by the Blue Sea 6010200 battery switch is 32V DC.
What size battery cables can be used with the Blue Sea 6010200 battery switch?
The Blue Sea 6010200 battery switch is designed to accommodate 4/0 AWG battery cables.
Does the Blue Sea 6010200 battery switch have an alternator field disconnect function?
The Blue Sea 6010200 battery switch does not inherently include an alternator field disconnect function. This feature is typically found on dedicated ACRs or specific charging relays.
